Valtra A84
The Valtra A84 is a tractor produced by Valtra. It is equipped with a 201.4 ci 3.3 L engine. The listed engine power is Diesel (listed): 82 hp / 61.1 kW. Transmission: 24 forward and reverse. Operating weight: 7716 lbs 3499 kg.
Engine Power
Diesel (listed): 82 hp / 61.1 kW
Fuel & Capacities
39.6 gal
149.9 L
Transmission
24 forward and reverse
Operating Weight
7716 lbs
3499 kg
Overview
 | 2017 - 2020
A SeriesUtility tractor
A Series
Utility tractor |
|---|
Production | |
|---|---|
Manufacturer | Valtra (a part of AGCO) |
Utility tractor | |
Valtra A84 Engine | |
|---|---|
AGCO Power 3.3L 3-cyl diesel | |
Fuel tank | 39.6 gal
149.9 L |
Exhaust fluid (DEF) | 5.3 gal
20.1 L |
Engine details ...  | |
Valtra A84 Power | |
|---|---|
Engine | 82 hp
61.1 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Wet disc brakes | |
Cab standard with available air-conditioning. |
Hydraulics | |
|---|---|
Type | open center |
Pump flow | 17.2 gpm
65.1 lpm |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | electro-hydraulic |
Rear PTO Type | 540/540E |
Engine RPM | 540@1920 |
540E@1560 | |
Dimensions & Tires | |
|---|---|
Wheelbase | 88.6 inches
225 cm |
Weight | 7716 lbs
3499 kg |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
A Series published in 2019, by Valtra |
Engine
Engine Detail — 201.4 ci / 3.3 L Diesel
Manufacturer | AGCO Power 33 AWFC |
Configuration | turbocharged intercooled diesel, 3-cylinder, liquid-cooled |
Displacement | 201.4 ci
3.3 L |
Bore/Stroke | 4.25x4.72 inches
108 x 120 mm |
Power | 82 hp
61.1 kW |
Maximum Power | 85 hp
63.4 kW |
Torque | 256 lb-ft
347.1 Nm |
Torque RPM | 1500 |
Starter | electric |
Starter volts | 12 |
Valtra A84 Engine | |
|---|---|
 |
Transmission
Transmission options | |
|---|---|
12-speed power shuttle | |
24-speed creeper |
Transmission — 12 forward and reverse power shuttle
Type | power shuttle |
Gears | 12 forward and reverse |
Transmission | |
Type | creeper |
Gears | 24 forward and reverse |
Dimensions
Valtra A84 Tires |
|---|
Dimensions | |
|---|---|
Wheelbase | 88.6 inches
225 cm |
Length | 160.6 inches
407 cm |
Height (cab) | 104.9 inches
266 cm |
Clearance (front axle) | 16.7 inches
42 cm |
Valtra A84 Weight | |
|---|---|
Operating | 7716 lbs
3499 kg |
Max capacity | 13669 lbs
6200 kg |
Max front axle | 6614 lbs
3000 kg |
Max rear axle | 11023 lbs
5000 kg |
Photos
Valtra A84 tractor photo
Recommended Implements & Sizing Guide
Engineering recommendations for Valtra A84 based on its 82 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 3 to 4 Bottom (16")3 - 4 铧 (40 cm) | Heavy Duty | Suitable for medium loam and stubble turnover. |
Rotary Cutter / MowerMowing & Clearing | 7 to 8 ft (84-96 in)2.1 - 2.4 m | Heavy Duty | Heavy-duty twin spindle cutter for overgrown acreage. |
Rotary TillerSeedbed Prep | 78 to 84 in200 - 215 cm | Heavy Duty | Heavy commercial tiller with multi-speed gearbox. |
Disc HarrowSecondary Tillage | 10 to 14 ft Tandem / Offset3.0 - 4.2 m 重型交错耙 | Heavy Duty | Aggressive residue cutting in corn/cotton stubble. |
Hay BalerHay & Forage | 4x4 to 4x5 Round Baler1.2x1.5 m 紧凑圆捆机 | Heavy Duty | Silage and dry hay; 540 RPM PTO with slip-clutch. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Valtra A84.
Estimated Continuous Field Runtime: 9.3 hrs
Approximately 9.3 hours of continuous field operation at ~75% rated power on a full tank (39.6 gal / 149.9 L).
Estimated 75% Load Fuel Burn~4.3 gal/hr (16.1 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Valtra A84 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Valtra A84.
Converted Equivalents:
Horsepower (HP)82 hp
Kilowatts (kW)61.1 kW
Metric Horsepower (PS / CV)83.1 PS
Direct Competitor Comparison
Compare Valtra A84 against same-era industry alternatives in the same horsepower class.
Current Model
Valtra
Valtra A84
Engine Power:Diesel (listed): 82 hp / 61.1 kW
★ Baseline Reference
International HarvesterMarket Competitor
International Harvester 844
Engine Power:73.8
Production Years:1974 - 1980
