Valtra A84

The Valtra A84 is a tractor produced by Valtra. It is equipped with a 201.4 ci 3.3 L engine. The rated power output is 82 hp 61.1 kW. Transmission: 24 forward and reverse. Operating weight: 7716 lbs 3499 kg.

Overview

	2017 - 2020 A SeriesUtility tractor
2017 - 2020
A Series
Utility tractor

Production
Manufacturer	Valtra (a part of AGCO)
Utility tractor

Valtra A84 Engine
AGCO Power 3.3L 3-cyl diesel
Fuel tank	39.6 gal 149.9 L
Exhaust fluid (DEF)	5.3 gal 20.1 L
Engine details ...

Valtra A84 Power
Engine	82 hp 61.1 kW

Mechanical
Four-wheel drive
Power steering
Wet disc brakes
Cab standard with available air-conditioning.

Hydraulics
Type	open center
Pump flow	17.2 gpm 65.1 lpm

Power Take-off (PTO)
Rear PTO	independent
Clutch	electro-hydraulic
Rear PTO Type	540/540E
Engine RPM	540@1920
	540E@1560

Dimensions & Tires
Wheelbase	88.6 inches 225 cm
Weight	7716 lbs 3499 kg
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References
A Series published in 2019, by Valtra

Engine

Engine Detail — 201.4 ci / 3.3 L Diesel

Manufacturer	AGCO Power 33 AWFC
Configuration	turbocharged intercooled diesel, 3-cylinder, liquid-cooled
Displacement	201.4 ci 3.3 L
Bore/Stroke	4.25x4.72 inches 108 x 120 mm
Power	82 hp 61.1 kW
Maximum Power	85 hp 63.4 kW
Torque	256 lb-ft 347.1 Nm
Torque RPM	1500
Starter	electric
Starter volts	12

Valtra A84 Engine

Transmission

Transmission options
12-speed power shuttle
24-speed creeper

Transmission — 12 forward and reverse power shuttle

Type	power shuttle
Gears	12 forward and reverse
Transmission
Type	creeper
Gears	24 forward and reverse

Dimensions

Valtra A84 Tires

Dimensions
Wheelbase	88.6 inches 225 cm
Length	160.6 inches 407 cm
Height (cab)	104.9 inches 266 cm
Clearance (front axle)	16.7 inches 42 cm

Valtra A84 Weight
Operating	7716 lbs 3499 kg
Max capacity	13669 lbs 6200 kg
Max front axle	6614 lbs 3000 kg
Max rear axle	11023 lbs 5000 kg

Photos

Valtra A84 tractor photo
