White 2-65
The White 2-65 is a tractor produced by White. It is equipped with a 235.3 ci 3.9 L engine. The rated power output is 62.50 hp 46.6 kW. Transmission: 16 forward and 4 reverse. Drive type: 4x2 2WD. Operating weight: 5314 to 6320 pounds.
Engine Power
62.50 hp
46.6 kW
Drive & Traction
4x2 2WD
Fuel & Capacities
15.9 gal
60.2 L
Transmission
16 forward and 4 reverse
Operating Weight
5314 to 6320 pounds
White 2-65 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1982 - 1987
Field Boss SeriesUtility tractorIseki built |
|---|---|
1982 - 1987 | |
Field Boss Series | |
Utility tractor | |
Iseki built | |
1982 - 1987 | |
|---|---|
Field Boss Series | |
Utility tractor | |
Iseki built |
Production | |
|---|---|
Distributor | White |
Manufacturer | Iseki |
Utility tractor | |
Built in Japan | |
Variants | |
|---|---|
Iseki T7000 | similar tractor |
White 2-65 Engine | |
|---|---|
Isuzu 3.9L 4-cyl diesel | |
Engine details ...  |
White 2-65 Transmission | |
|---|---|
16-speed synchromesh | |
Transmission details ...  |
White 2-65 Power | |
|---|---|
PTO (claimed) | 62.50 hp
46.6 kW |
Drawbar (tested) | 55.71 hp
41.5 kW |
PTO (tested) | 62.50 hp
46.6 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Drive | 4x2 2WD |
4x4 MFWD 4WD (optional) | |
Differential lock | foot-activated standard |
Steering | power |
Differential wet disc brakes | |
Two-post ROPS. Optional canopy. | |
Capacity | |
|---|---|
Fuel | 15.9 gal
60.2 L |
Hydraulic system | 10.3 gal
39.0 L |
Hydraulics | |
|---|---|
Type | open center |
Capacity | 10.3 gal
39.0 L |
Pressure | 2415 psi
166.5 bar |
Valves | 1 to 3 |
Total flow | 11.9 gpm
45.0 lpm |
Tractor hitch | |
|---|---|
Rear Type | II/I |
Rear lift (at 24"/610mm) | 3,762 lbs
1706 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/ground |
Dimensions & Tires | |
|---|---|
Wheelbase | 84.6 inches
214 cm |
Weight | 5314 to 6320 pounds |
Front tire | 7.50-16 |
Rear tire | 16.9-30 (2WD) |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Charging system | alternator |
Charging amps | 35 |
Batteries | 2 |
Battery volts | 12 |
References | |
|---|---|
 | |
1100 Series Front End Loaders published in 1987, by White | |
2-55/2-65/2-75 Field Boss Tractors published in 1986, by White |
Engine
| 1982 - 1987
Field Boss SeriesUtility tractorIseki built |
|---|---|
1982 - 1987 | |
Field Boss Series | |
Utility tractor | |
Iseki built | |
1982 - 1987 | |
|---|---|
Field Boss Series | |
Utility tractor | |
Iseki built |
Engine Detail — 235.3 ci / 3.9 L Diesel
Manufacturer | Isuzu |
Fuel Type | Diesel |
Configuration | 4-cylinder, liquid-cooled |
Displacement | 235.3 ci
3.9 L |
Bore/Stroke | 4.016x4.646 inches
102 x 118 mm |
Air cleaner | dry with pre-cleaner |
Pre-heating | glow plugs |
Compression | 17.5:1 |
Rated RPM | 2200 |
Idle RPM | 675-2420 |
Starter volts | 12 |
Oil capacity | 10.5 qts
9.9 L |
Coolant capacity | 15.2 qts
14.4 L |
Transmission
| 1982 - 1987
Field Boss SeriesUtility tractorIseki built |
|---|---|
1982 - 1987 | |
Field Boss Series | |
Utility tractor | |
Iseki built | |
1982 - 1987 | |
|---|---|
Field Boss Series | |
Utility tractor | |
Iseki built |
Transmission — 16 forward and 4 reverse synchromesh
Type | synchromesh |
Gears | 16 forward and 4 reverse |
Oil capacity | 41.3 qts
39.1 L |
Three gears, plus reverse, with high-low creeper and high-low auxiliary ranges. | |
With 16.9-30 rear tires. Speeds expressed as gear-creeper-auxiliary. | |
 | |
Dimensions
| 1982 - 1987
Field Boss SeriesUtility tractorIseki built |
|---|---|
1982 - 1987 | |
Field Boss Series | |
Utility tractor | |
Iseki built | |
1982 - 1987 | |
|---|---|
Field Boss Series | |
Utility tractor | |
Iseki built |
White 2-65 Tires | |
|---|---|
Standard tires (ag) | Front: 7.50-16. Rear: 16.9-30 (2WD) |
Front: 9.50-24. Rear: 16.9-30 (4WD) | |
Dimensions | |
|---|---|
Wheelbase | 84.6 inches
214 cm |
Length | 142.1 inches
360 cm |
Width | 73.5 inches
186 cm |
Height (exhaust) | 97 inches
246 cm |
Clearance (front axle) | 19.8 inches
50 cm |
White 2-65 Weight | |
|---|---|
Shipping | 5,314 lbs (2WD)
2410 kg |
Operating | 6,320 lbs (4WD)
2866 kg |
Ballasted | 7,110 lbs
3225 kg |
Tests
| 1982 - 1987
Field Boss SeriesUtility tractorIseki built |
|---|---|
1982 - 1987 | |
Field Boss Series | |
Utility tractor | |
Iseki built | |
1982 - 1987 | |
|---|---|
Field Boss Series | |
Utility tractor | |
Iseki built |
Nebraska Tractor Test 1467 | |
|---|---|
Diesel 16-speed 4WD
March 18 - April 20, 1983
Link: Nebraska Tractor Test 1467 file | |
PTO performance | |
Power at rated engine speed | 62.50 hp
46.6 kW |
Fuel use | 4.0 gal/hour
15.1 l/hour |
Power at rated PTO speed | 55.40 hp
41.3 kW |
Fuel use | 3.4 gal/hour
12.9 l/hour |
Drawbar performance | |
Max power | 55.71 hp
41.5 kW |
Fuel use | 4.0 gal/hour
15.1 l/hour |
Gear 4HL used for power test. | |
Max pull | 4,827 lbs
2189 kg |
Gear 3HL used for pull test. | |
