Yanmar AF-26
The Yanmar AF-26 is a tractor produced by Yanmar. It is equipped with a 91.29 ci 1.5 L engine. The rated power output is 25.6 hp 19.1 kW. Transmission: 16 forward and reverse. Operating weight: 2701 lbs 1225 kg.
Engine Power
25.6 hp
19.1 kW
Fuel & Capacities
10 gal
37.9 L
Transmission
16 forward and reverse
Operating Weight
2701 lbs
1225 kg
Yanmar AF-26 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1992 - 1997
AF SeriesCompact Utility tractor |
|---|---|
1992 - 1997 | |
AF Series | |
Compact Utility tractor | |
Production | |
|---|---|
Manufacturer | Yanmar |
Compact Utility tractor | |
Yanmar AF-26 Engine | |
|---|---|
Yanmar 1.5L 3-cyl diesel | |
Fuel tank | 10 gal
37.9 L |
Engine details ...  | |
Yanmar AF-26 Power | |
|---|---|
Engine | 25.6 hp
19.1 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Two-post ROPS. Cab optional. |
Tractor hitch | |
|---|---|
Rear Type | JIS1 |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540 (1.375) |
Engine RPM | 551@2500 |
756@2500 | |
963@2500 | |
1293@2500 | |
-694@2500 | |
Dimensions & Tires | |
|---|---|
Wheelbase | 64.6 inches
164 cm |
Weight | 2701 lbs
1225 kg |
Front tire | 7-16 |
Rear tire | 11.2-24 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 35 |
Battery volts | 12 |
Battery AH | 70 |
References | |
|---|---|
 | |
Super-Forte Mark III (198071-90015) published in 1992 |
Engine
Engine Detail — 91.29 ci / 1.5 L Diesel
Manufacturer | Yanmar 3TNS84 |
Fuel Type | Diesel |
Configuration | 3-cylinder, liquid-cooled |
Displacement | 91.29 ci
1.5 L |
Bore/Stroke | 3.31x3.54 inches
84 x 90 mm |
Power | 25.6 hp
19.1 kW |
Rated RPM | 2500 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission options | |
|---|---|
16-speed shuttle | |
16-speed four-speed power shift |
Transmission — 16 forward and reverse shuttle
Type | shuttle |
Gears | 16 forward and reverse |
Four gears in three ranges, plus creeper range with mechincal shuttle. | |
 | |
Transmission — 16 forward and reverse four-speed power shift
Type | four-speed power shift |
Gears | 16 forward and reverse |
Four power shift gears in three ranges, plus creeper range with power shuttle | |
Dimensions
Yanmar AF-26 Tires | |
|---|---|
Standard tires (ag) | Front: 7-16. Rear: 11.2-24 |
Dimensions | |
|---|---|
Wheelbase | 64.6 inches
164 cm |
Length | 116.5 inches
295 cm |
Width | 53.5 inches
135 cm |
Height | 76.4 inches
194 cm |
Weight | 2701 lbs
1225 kg |
Ground clearance | 12.6 inches
32 cm |
Front tread | 42.5 inches
107 cm |
Rear tread | 41.7 to 53.5 inches
105 to 135 cm |
Photos
Yanmar AF-26 tractor photo
