Yanmar YM2002
The Yanmar YM2002 is a tractor produced by Yanmar. It is equipped with a 78.1 ci 1.3 L engine. The listed engine power is Diesel (listed): 20 hp / 14.9 kW. Transmission: 15 forward and 5 reverse. Operating weight: 2314 lbs 1049 kg.
Engine Power
Diesel (listed): 20 hp / 14.9 kW
Fuel & Capacities
Diesel
Transmission
15 forward and 5 reverse
Operating Weight
2314 lbs
1049 kg
Overview
 | 1982 - 1983
YM02 SeriesCompact Utility tractor
YM02 Series
Compact Utility tractor |
|---|
Production | |
|---|---|
Manufacturer | Yanmar |
Compact Utility tractor | |
Variants | |
|---|---|
YM2002 | 2WD gear |
YM2002D | 4WD gear |
YM2020 | 2WD power shift |
YM2020D | 4WD power shift |
Yanmar YM2002 Engine | |
|---|---|
Yanmar 1.3L 3-cyl diesel | |
Engine details ...  |
Yanmar YM2002 Transmission | |
|---|---|
15-speed gear | |
Transmission details ...  |
Yanmar YM2002 Power | |
|---|---|
Engine | 20 hp
14.9 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Open operator station. |
Dimensions & Tires | |
|---|---|
Weight | 2314 lbs
1049 kg |
Full dimensions and tires ...  | |
Engine
Engine Detail — 78.1 ci / 1.3 L Diesel
Manufacturer | Yanmar 3T80U-NA |
Fuel Type | Diesel |
Configuration | 3-cylinder, liquid-cooled |
Displacement | 78.1 ci
1.3 L |
Power | 20 hp
14.9 kW |
Rated RPM | 2400 |
Transmission
Transmission — 15 forward and 5 reverse gear
Type | gear |
Gears | 15 forward and 5 reverse |
 | |
Dimensions
Yanmar YM2002 Tires |
|---|
Dimensions | |
|---|---|
Length | 104 inches
264 cm |
Width | 45 inches
114 cm |
Height | 71 inches
180 cm |
Weight | 2314 lbs
1049 kg |
Photos
Yanmar YM2002
Recommended Implements & Sizing Guide
Engineering recommendations for Yanmar YM2002 based on its 20 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 1 to 2 Bottom (12")1 - 2 铧 (30 cm) | Light Duty | Ideal for garden plots and light sandy soil. |
Rotary Cutter / MowerMowing & Clearing | 4 ft (48 in)1.2 m | Light Duty | Pasture clipping and light brush under 1" diameter. |
Rotary TillerSeedbed Prep | 42 to 48 in105 - 120 cm | Light Duty | Covers compact tractor tire width. |
Disc HarrowSecondary Tillage | 5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片) | Light Duty | Small acreage soil break-up and secondary aeration. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Yanmar YM2002.
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Yanmar YM2002 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Yanmar YM2002.
Converted Equivalents:
Horsepower (HP)20 hp
Kilowatts (kW)14.9 kW
Metric Horsepower (PS / CV)20.3 PS
