Amigo 1400
The Amigo 1400 is a tractor produced by Amigo Lawn Tractors. The listed engine power is Gasoline (listed): 10 hp / 7.5 kW. Transmission: Amigo-Matic.
Engine Power
Gasoline (listed): 10 hp / 7.5 kW
Fuel & Capacities
Gasoline
Transmission
Amigo-Matic
Overview
![]() | 1965 - 1966
Garden tractor |
|---|
Production | |
|---|---|
Manufacturer | Amigo |
Garden tractor | |
Built in Dowagiac, Michigan, USA | |
Amigo 1400 Engine | |
|---|---|
10HP Wisconsin gasoline | |
Engine details ... |
Amigo 1400 Transmission | |
|---|---|
4-speed | |
Transmission details ... |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | manual |
Open operator station. | |
Power Take-off (PTO) | |
|---|---|
Rear PTO | live |
Front PTO | live |
Dimensions & Tires | |
|---|---|
Wheelbase | 44 inches
111 cm |
Front tire | 5.50x8-16 |
Rear tire | 8.00x12-22 |
Full dimensions and tires ... | |
Engine
Engine Detail — Gasoline
Manufacturer | Wisconsin TRA 10D |
Fuel Type | Gasoline |
Configuration | air-cooled |
Power | 10 hp
7.5 kW |
Transmission
Transmission — Amigo-Matic
Transmission | Amigo-Matic |
Gears | 4 forward and 2 reverse |
Dimensions
Amigo 1400 Tires | |
|---|---|
Lawn/turf front | 5.50x8-16 |
Lawn/turf rear | 8.00x12-22 |
Dimensions | |
|---|---|
Wheelbase | 44 inches
111 cm |
Length | 62 inches
157 cm |
Width | 36 inches
91 cm |
Height | 39 inches
99 cm |
Photos
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Amigo Lawn Tractors Amigo 1400.
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Amigo Lawn Tractors Amigo 1400 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Amigo Lawn Tractors Amigo 1400.
Converted Equivalents:
Horsepower (HP)10 hp
Kilowatts (kW)7.5 kW
Metric Horsepower (PS / CV)10.1 PS
