Belarus 922
The Belarus 922 is a tractor produced by Belarus. It is equipped with a 289.8 ci 4.7 L engine. The rated power output is 100 hp 74.6 kW. Transmission: 18 forward and 4 reverse. Operating weight: 7870 lbs 3569 kg.
Engine Power
100 hp
74.6 kW
Fuel & Capacities
34.3 gal
129.8 L
Transmission
18 forward and 4 reverse
Operating Weight
7870 lbs
3569 kg
Belarus 922 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1984 - 1993
Row-Crop tractor |
|---|---|
1984 - 1993 | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | Belarus |
Row-Crop tractor | |
Built in Minsk, Belarus | |
Original price was $23,000 in 1993 | |
Belarus 922 Engine | |
|---|---|
Belarus 4.7L 4-cyl diesel | |
Engine details ...  |
Belarus 922 Transmission | |
|---|---|
18-speed gear | |
Transmission details ...  |
Belarus 922 Power | |
|---|---|
Engine | 100 hp
74.6 kW |
PTO (claimed) | 88 hp
65.6 kW |
Mechanical | |
|---|---|
Two-wheel drive | |
Final drives | spur gear |
Differential lock | mechanical rear |
Power steering | |
Disc brakes | |
Cab standard with heat. | |
Capacity | |
|---|---|
Fuel | 34.3 gal
129.8 L |
Hydraulic system | 5.4 gal
20.4 L |
Steering | 6.3 qts
6.0 L |
Hydraulics | |
|---|---|
Type | open center |
Capacity | 5.4 gal
20.4 L |
Pressure | 2274 psi
156.8 bar |
Valves | 2 |
Pump flow | 11.8 gpm
44.7 lpm |
Steering cap. | 6.3 qts
6.0 L |
Tractor hitch | |
|---|---|
Rear Type | II |
Control | position and draft control |
Rear lift (at ends) | 4400 lbs
1995 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 (1.375) |
Engine RPM | 540@2068 |
1000@2158 | |
Dimensions & Tires | |
|---|---|
Wheelbase | 96.5 inches
245 cm |
Weight | 7870 lbs
3569 kg |
Front tire | 11.2-20 |
Rear tire | 15.5-38 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
Operators Manual 500 Series, 800 Series and 900 Series Tractors (904805) published in 1992 | |
922 published by Belarus* | |
*Publication contains known errors. |
Engine
Engine Detail — 289.8 ci / 4.7 L Diesel
Manufacturer | Belarus |
Configuration | turbocharged diesel, 4-cylinder, liquid-cooled |
Displacement | 289.8 ci
4.7 L |
Bore/Stroke | 4.33x4.92 inches
110 x 125 mm |
Power | 100 hp
74.6 kW |
Air cleaner | oil bath |
Compression | 16:1 |
Rated RPM | 2200 |
Torque | 197 lb-ft
267.1 Nm |
Torque RPM | 1000 |
Starter | electric |
Starter volts | 24 |
Oil capacity | 15.8 qts
15.0 L |
Coolant capacity | 21.1 qts
20.0 L |
Transmission
Transmission — 18 forward and 4 reverse gear
Type | gear |
Gears | 18 forward and 4 reverse |
Clutch | 325.1mm dry disc |
Oil capacity | 42.2 qts
39.9 L |
 | |
Dimensions
Belarus 922 Tires | |
|---|---|
Ag front | 11.2-20 |
Ag rear | 15.5-38 |
Ag rear | 15x30 |
Dimensions | |
|---|---|
Wheelbase | 96.5 inches
245 cm |
Shipping weight | 7870 lbs
3569 kg |
Front tread | 47 to 71 inches
119 to 180 cm |
Rear tread | 47 to 71 inches
119 to 180 cm |
Photos
Belarus 922
