Bolinder-Munktell 230

The Bolinder-Munktell 230 is a tractor produced by Bolinder Munktell. It is equipped with a 136.7 ci 2.2 L engine. The listed engine power is Diesel (listed): 29 hp / 21.6 kW; Diesel (listed): 2.5 hp / 1.9 kW. Transmission: 5 forward and 1 reverse. Operating weight: 4211 lbs 1910 kg.

Engine Power

Diesel (listed): 29 hp / 21.6 kW; Diesel (listed): 2.5 hp / 1.9 kW

Fuel & Capacities

13.2 gal 50.0 L

Transmission

5 forward and 1 reverse

Operating Weight

4211 lbs 1910 kg

Overview

Note: the Bolinder-Munktell model 230 is the same as the Volvo T230. The following data is from the T230 listing.

Production
Manufacturer	Bolinder-Munktell
Total built	4976

Bolinder-Munktell 230 Engine
Bolinder 2.2L 2-cyl diesel
Fuel tank	13.2 gal 50.0 L
Engine details ...

Bolinder-Munktell 230 Transmission
5-speed gear
Transmission details ...

Bolinder-Munktell 230 Power
Engine	29 hp 21.6 kW
Belt (claimed)	27 hp 20.1 kW

Mechanical
Two-wheel drive
Disc brakes
Open operator station.

Hydraulics
Type	open center
Pressure	1595 psi 110.0 bar

Tractor hitch
Rear Type	I
Rear lift	1433 lbs 650 kg

Power Take-off (PTO)
Rear PTO Type	540
Engine RPM	540@1700

Dimensions & Tires
Wheelbase	72.83 inches 184 cm
Weight	4211 lbs 1910 kg
Front tire	5.5x16
Rear tire	11x28
Full dimensions and tires ...

Electrical
Charging system	alternator
Battery volts	12

References

Move up to John Deere... published in 1981

Engine

Note: the Bolinder-Munktell model 230 is the same as the Volvo T230. The following data is from the T230 listing.

Engine Detail — 136.7 ci / 2.2 L Diesel

Manufacturer	Bolinder 1052
Fuel Type	Diesel
Configuration	2-cylinder, liquid-cooled
Displacement	136.7 ci 2.2 L
Bore/Stroke	4.135x5.118 inches 105 x 130 mm
Power	29 hp 21.6 kW
Fuel system	direct injection
Air cleaner	oil bath
Compression	16.5:1
Rated RPM	1700
Torque	1215 lb-ft 1647.5 Nm
Torque RPM	1000
Starter volts	12
Starter power	2.5 hp 1.9 kW
Oil capacity	9 qts 8.5 L
Coolant capacity	9.5 qts 9.0 L
Intake valve clearance	0.018 inches (hot) 0.457 mm
Exhaust valve clearance	0.018 inches (hot) 0.457 mm

Transmission

Note: the Bolinder-Munktell model 230 is the same as the Volvo T230. The following data is from the T230 listing.

Transmission — 5 forward and 1 reverse gear

Type	gear
Gears	5 forward and 1 reverse
Clutch	dry disc
Oil capacity	7.4 qts 7.0 L

Dimensions

Note: the Bolinder-Munktell model 230 is the same as the Volvo T230. The following data is from the T230 listing.

Bolinder-Munktell 230 Tires
Ag front	5.5x16
Ag rear	11x28

Dimensions
Wheelbase	72.83 inches 184 cm
Length	112.2 inches 284 cm
Weight	4211 lbs 1910 kg

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Bolinder Munktell Bolinder-Munktell 230.

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours
