Branson 3620H
The Branson 3620H is a tractor produced by Branson. It is equipped with a 104.5 ci 1.7 L engine. The listed engine power is Diesel (listed): 35 hp / 26.1 kW. Transmission: infinite forward and reverse (4-range). Operating weight: 3714 lbs 1684 kg.
Engine Power
Diesel (listed): 35 hp / 26.1 kW
Fuel & Capacities
11.8 gal
44.7 L
Transmission
infinite forward and reverse (4-range)
Operating Weight
3714 lbs
1684 kg
Overview
 | 2021 -
Compact Utility tractor |
|---|---|
2021 - | |
Compact Utility tractor | |
Production | |
|---|---|
Manufacturer | Branson (a part of TYM) |
Compact Utility tractor | |
Variants | |
|---|---|
3620R | shuttle |
3620H | hydrostatic |
Branson 3620H Engine | |
|---|---|
Kukje 1.7L 3-cyl diesel | |
Fuel tank | 11.8 gal
44.7 L |
Engine details ...  | |
Branson 3620H Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Branson 3620H Power | |
|---|---|
Engine | 35 hp
26.1 kW |
PTO (claimed) | 29.6 hp
22.1 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Two-post folding ROPS. |
Hydraulics | |
|---|---|
Pump flow | 13.7 gpm
51.9 lpm |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540 (1.375) |
Engine RPM | 584@2600 |
Dimensions & Tires | |
|---|---|
Wheelbase | 71.1 inches
180 cm |
Weight | 3714 lbs
1684 kg |
Front tire | 9.5-16 |
Rear tire | 12.4-28 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
20 Series published in 2021, by Branson |
Engine
Engine Detail — 104.5 ci / 1.7 L Diesel
Manufacturer | Kukje |
Fuel Type | Diesel |
Configuration | 3-cylinder, liquid-cooled |
Displacement | 104.5 ci
1.7 L |
Bore/Stroke | 3.465x3.701 inches
88 x 94 mm |
Emissions | Tier IV |
Power | 35 hp
26.1 kW |
Air cleaner | dual dry |
Rated RPM | 2600 |
Transmission
Transmission — infinite forward and reverse (4-range) hydrostatic
Type | hydrostatic |
Gears | infinite forward and reverse (4-range) |
Dimensions
Branson 3620H Tires | |
|---|---|
Standard tires (ag) | Front: 9.5-16. Rear: 12.4-28 |
Lawn/turf front | 29x12.5-15 |
Lawn/turf rear | 44x18.00-20 |
Industrial front | 10-16.5 |
Industrial rear | 420/70-24 |
Dimensions | |
|---|---|
Wheelbase | 71.1 inches
180 cm |
Length | 127.4 inches
323 cm |
Width | 64.9 inches
164 cm |
Height (ROPS) | 98.4 inches
249 cm |
Weight | 3714 lbs
1684 kg |
Ground clearance | 15.5 inches
39 cm |
Attachments
Attachment overview | |
|---|---|
Front-end loader | |
Backhoe |
Branson BH250 Backhoe | |
|---|---|
Backhoe type | Branson BH250 Backhoe |
Transport height | 91.2 inches
231 cm |
2-Foot flat digging depth | 103.2 inches
262 cm |
Reach from pivot | 134.4 inches
341 cm |
Loading height | 92.4 inches
234 cm |
Bucket Rotation | 151° |
Swing Arc | 180° |
Recommended Implements & Sizing Guide
Engineering recommendations for Branson 3620H based on its 35 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 2 to 3 Bottom (14-16")2 - 3 铧 (35-40 cm) | Medium Duty | Standard utility farm tillage. |
Rotary Cutter / MowerMowing & Clearing | 5 ft (60 in)1.5 m | Medium Duty | Pasture maintenance and weeds up to 1.5" diameter. |
Rotary TillerSeedbed Prep | 54 to 60 in135 - 150 cm | Medium Duty | Thorough seedbed preparation in orchards and vegetable plots. |
Disc HarrowSecondary Tillage | 5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片) | Light Duty | Small acreage soil break-up and secondary aeration. |
Hay BalerHay & Forage | Small Square Baler (14x18")小方捆打捆机 (36x46 cm) | Medium Duty | Classic 2-string baler for horse and small livestock hay. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Branson 3620H.
Estimated Continuous Field Runtime: 6.5 hrs
Approximately 6.5 hours of continuous field operation at ~75% rated power on a full tank (11.8 gal / 44.7 L).
Estimated 75% Load Fuel Burn~1.8 gal/hr (6.9 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Branson 3620H Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Branson 3620H.
Converted Equivalents:
Horsepower (HP)35 hp
Kilowatts (kW)26.1 kW
Metric Horsepower (PS / CV)35.5 PS
Direct Competitor Comparison
Compare Branson 3620H against same-era industry alternatives in the same horsepower class.
Current Model
Branson
Branson 3620H
Engine Power:Diesel (listed): 35 hp / 26.1 kW
★ Baseline Reference
