Branson 4015R
The Branson 4015R is a tractor produced by Branson. It is equipped with a 104.6 ci 1.7 L engine. The listed engine power is Diesel (listed): 40 hp / 29.8 kW. Transmission: 12 forward and reverse. Operating weight: 3014 lbs 1367 kg.
Engine Power
Diesel (listed): 40 hp / 29.8 kW
Fuel & Capacities
7 gal
26.5 L
Transmission
12 forward and reverse
Operating Weight
3014 lbs
1367 kg
Overview
 | 2015 - 2023
15 SeriesCompact Utility tractor
15 Series
Compact Utility tractor |
|---|
Production | |
|---|---|
Manufacturer | Branson (a part of Kukje) |
Compact Utility tractor | |
Built in South Korea | |
Variants | |
|---|---|
4015R | shuttle |
4015H | hydrostatic |
Branson 4015R Engine | |
|---|---|
Kukje 1.7L 3-cyl diesel | |
Fuel tank | 7 gal
26.5 L |
Engine details ...  | |
Branson 4015R Transmission | |
|---|---|
12-speed synchronized shuttle | |
Transmission details ...  |
Branson 4015R Power | |
|---|---|
Engine | 40 hp
29.8 kW |
PTO (claimed) | 25.7 hp
19.2 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Differential lock | mechanical rear |
Power steering | |
Hydraulic wet disc brakes | |
Two-post folding ROPS. | |
Hydraulics | |
|---|---|
Pump flow | 8.7 gpm
32.9 lpm |
Steering flow | 4.7 gpm
17.8 lpm |
Tractor hitch | |
|---|---|
Rear Type | I |
Control | position control |
Rear lift (at ends) | 3306 lbs
1499 kg |
Rear lift (at 24"/610mm) | 2420 lbs
1097 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/540E |
Dimensions & Tires | |
|---|---|
Wheelbase | 65.8 inches
167 cm |
Weight | 3014 lbs
1367 kg |
Front tire | 7x16 |
Rear tire | 12.4x24 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
15 Series published in 2019, by Branson |
Engine
Engine Detail — 104.6 ci / 1.7 L Diesel
Manufacturer | Kukje A1700T2 |
Configuration | turbocharged diesel, 3-cylinder, liquid-cooled |
Displacement | 104.6 ci
1.7 L |
Bore/Stroke | 3.46x3.70 inches
88 x 94 mm |
Emissions | Tier 4 |
Power | 40 hp
29.8 kW |
Air cleaner | dry |
Rated RPM | 2600 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — 12 forward and reverse synchronized shuttle
Type | synchronized shuttle |
Gears | 12 forward and reverse |
Dimensions
Branson 4015R Tires | |
|---|---|
Ag front | 7x16 |
Ag rear | 12.4x24 |
Industrial front | 28x8.50-15 |
Industrial rear | 43x16-20 |
Dimensions | |
|---|---|
Wheelbase | 65.8 inches
167 cm |
Length | 118 inches
299 cm |
Width | 57 inches
144 cm |
Height (ROPS) | 94 inches
238 cm |
Height (Folded ROPS) | 60 inches
152 cm |
Weight | 3014 lbs
1367 kg |
Ground clearance | 12 inches
30 cm |
Photos
Branson 4015R tractor photo
Recommended Implements & Sizing Guide
Engineering recommendations for Branson 4015R based on its 40 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 2 to 3 Bottom (14-16")2 - 3 铧 (35-40 cm) | Medium Duty | Standard utility farm tillage. |
Rotary Cutter / MowerMowing & Clearing | 6 ft (72 in)1.8 m | Medium Duty | Medium pasture clearing; rear slip-clutch recommended. |
Rotary TillerSeedbed Prep | 66 to 72 in165 - 180 cm | Medium Duty | Standard utility tiller; slip clutch protection required. |
Disc HarrowSecondary Tillage | 7 to 8 ft Tandem Disc2.1 - 2.4 m 对开双排耙 | Medium Duty | Field leveling and clod breaking behind plows. |
Hay BalerHay & Forage | Small Square Baler (14x18")小方捆打捆机 (36x46 cm) | Medium Duty | Classic 2-string baler for horse and small livestock hay. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Branson 4015R.
Estimated Continuous Field Runtime: 3.4 hrs
Approximately 3.4 hours of continuous field operation at ~75% rated power on a full tank (7 gal / 26.5 L).
Estimated 75% Load Fuel Burn~2.1 gal/hr (7.9 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Branson 4015R Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Branson 4015R.
Converted Equivalents:
Horsepower (HP)40 hp
Kilowatts (kW)29.8 kW
Metric Horsepower (PS / CV)40.6 PS
Direct Competitor Comparison
Compare Branson 4015R against same-era industry alternatives in the same horsepower class.
Current Model
Branson
Branson 4015R
Engine Power:Diesel (listed): 40 hp / 29.8 kW
★ Baseline Reference
