CaseIH Farmall DX29

The CaseIH Farmall DX29 is a tractor produced by Caseih. It is equipped with a 81.2 ci 1.3 L engine. The listed engine power is Diesel (gross): 29 hp / 21.6 kW. Transmission: 9 forward and 3 reverse. Operating weight: 2474 lbs (hydro) 1122 kg.

Engine Power

Diesel (gross): 29 hp / 21.6 kW

Fuel & Capacities

7.3 gal 27.6 L

Transmission

9 forward and 3 reverse

Operating Weight

2474 lbs (hydro) 1122 kg

Overview

	2003 - 2005 Farmall DX SeriesCompact Utility tractor Farmall DX Series Compact Utility tractor

Production
Manufacturer	CaseIH (a part of CNH)
Compact Utility tractor

Variants
TC29DA	similar New Holland model

CaseIH Farmall DX29 Engine
Shibaura 1.3L 3-cyl diesel
Fuel tank	7.3 gal 27.6 L
Engine details ...

CaseIH Farmall DX29 Power
Engine (gross)	29 hp 21.6 kW
Hydro PTO (claimed)	23.6 hp 17.6 kW
Gear PTO (claimed)	25 hp 18.6 kW

Mechanical
Four-wheel drive
Steering	hydrostatic power
Wet disc brakes
Two-post folding ROPS.

Hydraulics
Type	open center
Pump flow	7.6 gpm 28.8 lpm
Total flow	12.7 gpm 48.1 lpm

Tractor hitch
Rear Type	I
Rear lift (at 24"/610mm)	1635 lbs 741 kg

Power Take-off (PTO)
Gear Rear PTO	transmision
Hydro Rear PTO	independent
Rear PTO Type	540 (1.375)
Gear Mid PTO	transmision
Hydro Mid PTO	independent
Mid PTO Type	2000 (1.0)

Dimensions & Tires
Wheelbase	63 inches 160 cm
Weight	2440 to 2474 pounds
Full dimensions and tires ...

References

DX Series Farmall Tractors published in 2004, by CaseIH
DX Series Farmall Tractors published in 2003, by CaseIH
DX Series Farmall Tractors and Integrated Implements published in 2004, by CaseIH

Engine

Engine Detail — 81.2 ci / 1.3 L Diesel

Manufacturer	Shibaura
Fuel Type	Diesel
Configuration	3-cylinder, liquid-cooled inline
Displacement	81.2 ci 1.3 L
Bore/Stroke	3.307x3.15 inches 84 x 80 mm
Power (gross)	29 hp 21.6 kW
Rated RPM	2800

Transmission

Transmission options
hydrostatic
9-speed gear

Transmission — infinite forward and reverse hydrostatic

Type	hydrostatic
Gears	infinite forward and reverse

Transmission — 9 forward and 3 reverse gear

Type	gear
Gears	9 forward and 3 reverse

Dimensions

CaseIH Farmall DX29 Tires

Dimensions
Wheelbase	63 inches 160 cm
Weight	2474 lbs (hydro) 1122 kg
	2440 lbs (gear) 1106 kg

Attachments

Attachment overview
60" mid-mount mower deck
72" mid-mount mower deck
Snowblower
Front-end loader

Photos

CaseIH Farmall DX29 tractor photo

Recommended Implements & Sizing Guide

Engineering recommendations for Caseih Farmall DX29 based on its 29 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	1 to 2 Bottom (12")1 - 2 铧 (30 cm)	Light Duty	Ideal for garden plots and light sandy soil.
Rotary Cutter / MowerMowing & Clearing	5 ft (60 in)1.5 m	Medium Duty	Pasture maintenance and weeds up to 1.5" diameter.
Rotary TillerSeedbed Prep	54 to 60 in135 - 150 cm	Medium Duty	Thorough seedbed preparation in orchards and vegetable plots.
Disc HarrowSecondary Tillage	5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片)	Light Duty	Small acreage soil break-up and secondary aeration.

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Caseih Farmall DX29.

Estimated Continuous Field Runtime: 4.8 hrs

Approximately 4.8 hours of continuous field operation at ~75% rated power on a full tank (7.3 gal / 27.6 L).

Estimated 75% Load Fuel Burn~1.5 gal/hr (5.7 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours
