CaseIH MXU125

The CaseIH MXU125 is a tractor produced by Caseih. It is equipped with a 410.6 ci 6.7 L engine. The rated power output is 125 hp 93.2 kW. Transmission: 16 forward and reverse. Operating weight: 10053 to 12065 pounds.

Overview

	2004 - 2006 MXU Maxxum SeriesUtility tractor
2004 - 2006
MXU Maxxum Series
Utility tractor

Production
Manufacturer	CaseIH
Utility tractor
Built in Basildon, England
Original price was $52,400 in 2005

Variants
TS125A	similar New Holland model

CaseIH MXU125 Engine
CNH 6.7L 6-cyl diesel
Fuel tank	67 gal 253.6 L
Engine details ...

CaseIH MXU125 Power
Engine (gross)	125 hp 93.2 kW
PTO (claimed)	105 hp 78.3 kW
Drawbar (tested)	88.5 hp 66.0 kW
PTO (tested)	121.2 hp 90.4 kW
Performance test details ...

Mechanical
Two- or four-wheel drive
Final drives	planetary inboard
Differential lock	electro-hydraulic rear standard
	front optional
Power steering
Differential hydraulic wet disc brakes
Two-post ROPS. Cab optional.

Hydraulics
Type	open center
	pressure-flow compensated (PFC)OptOptional
Pressure	2974 psi 205.1 bar
	3118 psi (PFC) 215.0 bar
Rear valves	2 to 4
Pump flow	19.8 gpm 74.9 lpm
	26.5 gpm (PFC) 100.3 lpm
Total flow	30.3 gpm 114.7 lpm
	37 gpm (PFC) 140.0 lpm
Steering flow	10.5 gpm 39.7 lpm

Tractor hitch
Rear Type	II (ROPS)
	II/IIIN (cab)
Control	mechanical lower link (ROPS)
	electronic draft control (cab)
Rear lift	9,285 lbs 4211 kg
	12,185 lbs (with cab) 5527 kg

Power Take-off (PTO)
Rear PTO	independent
Clutch	electro-hydraulic wet plates
Rear PTO Type	540/1000
Engine RPM	540@1969
	1000@2120

Dimensions & Tires
2WD Wheelbase	104.4 inches 265 cm
4WD Wheelbase	104.7 inches 265 cm
Weight	10053 to 12065 pounds
Front tire	10.00x16
2WD Rear tire	18.4R38
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	70 (ROPS)
	120 (cab)
Battery CCA	1300
Battery volts	12

References
MXU Series Maxxum Tractors published in 2004, by CaseIH
MXU Series Maxxum Tractors published in 2005, by CaseIH
TS1610-TS2810
TS1610-TS1910-TD2202-TD2205

Engine

Engine Detail — 410.6 ci / 6.7 L Diesel

Manufacturer	CNH
Configuration	turbocharged intercooled diesel, 6-cylinder, liquid-cooled
Displacement	410.6 ci 6.7 L
Bore/Stroke	4.094x5.196 inches 104 x 132 mm
Power (gross)	125 hp 93.2 kW
Fuel system	Bosch electronic direct injection with 8-hole injectors
Air cleaner	dual paper elements
Pre-heating	grid heater
Compression	17.0:1
Rated RPM	2200
Starter	electric
Starter volts	12

CaseIH MXU125 Engine

Transmission

Transmission options
24-speed partial powershift
16-speed partial powershift

Transmission — 24 forward and reverse partial powershift

Type	partial powershift
Gears	24 forward and reverse
Clutch	electro-hydraulic wet discs
Four gears (1-4) in three ranges (I-II-III) with low-high power shift. Gears and ranges are synchronized.

Transmission — 16 forward and reverse partial powershift

Type	partial powershift
Gears	16 forward and reverse
Clutch	electro-hydraulic wet discs
Four gears (1-4) in four ranges (A-D). Power shift between gears. Auto Shift feature automatically matches shifts within selected range to match load.

Dimensions

CaseIH MXU125 Tires
2WD Standard tires (ag)	Front: 10.00x16. Rear: 18.4R38
4WD Standard tires (ag)	Front: 14.9R28. Rear: 18.4R38

Dimensions
2WD Wheelbase	104.4 inches 265 cm
4WD Wheelbase	104.7 inches 265 cm

CaseIH MXU125 Weight
Shipping	10,053 lbs (2WD ROPS) 4560 kg
	10,979 lbs (2WD cab) 4980 kg
	10,427 lbs (4WD ROPS) 4729 kg
	11,331 lbs (4WD cab) 5139 kg
Operating	12,065 lbs (4WD cab) 5472 kg

CaseIH MXU125 Height
ROPS	114.1 inches 289 cm
Cab	114.1 inches 289 cm
	116.7 inches (suspended cab) 296 cm
Exhaust	114.9 inches 291 cm

Tests

OCED Tractor Test 2259
Diesel 24-speed 4WD March 1 - May 1, 2005 Link: OCED Tractor Test 2259 file
PTO performance
Max power	121.2 hp 90.4 kW
Fuel use	6.6 gal/hour 25.0 l/hour
Power at rated engine speed	109.4 hp 81.6 kW
Fuel use	6.7 gal/hour 25.4 l/hour
Power at rated PTO speed	113.6 hp 84.7 kW
Fuel use	6.6 gal/hour 25.0 l/hour
Drawbar performance
Max power	88.5 hp 66.0 kW
Fuel use	6.7 gal/hour 25.4 l/hour
Gear 12 used for power test.
Max pull	12,770 lbs 5792 kg
Gear 1-I-Hi used for pull test.

Attachments

Attachment overview
CaseIH LX156 loader

Photos

CaseIH MXU125 tractor photo
