Deutz-Allis 8070

The Deutz-Allis 8070 is a tractor produced by Deutz Allis. It is equipped with a 426 ci 7.0 L engine. The rated power output is 170.72 hp 127.3 kW. Transmission: Power Shift. Operating weight: 16850 to 17300 pounds.

Overview

	1985 - 1988 Row-Crop tractor
1985 - 1988
Row-Crop tractor

Series map: 9170↑ 1989-1990805080706080169.3hp*189.7hp*93.0hp*8070↓ 1982-1985*Estimated engine power for comparison only.

Note: the Deutz-Allis model 8070 is the same as the Allis Chalmers 8070. The following data is from the 8070 listing.

Production
Manufacturer	Deutz-Allis
Row-Crop tractor
Built in West Allis, Wisconsin, USA
Total built	2,354
Original price	$60,337

Deutz-Allis 8070 Engine
Allis Chalmers 7.0L 6-cyl diesel
Engine details ...

Deutz-Allis 8070 Power
Drawbar (tested)	145.36 hp 108.4 kW
PTO (tested)	170.72 hp 127.3 kW
Performance test details ...

Mechanical
Two- or four-wheel drive
Differential lock	electro-hydraulic rear
Steering	hydrostatic power
Differential hydraulic wet discs brakes
Acousta cab standard with heat and air-conditioning. Optional radio and cassette tape player.

Capacity
Fuel	60 gal 227.1 L
	25 gal (optional tank) 94.6 L
Rear diff.	68.4 qts 64.7 L

Hydraulics
Type	closed-center load-sensitive
Valves	2 or 3
Pump flow	22 gpm 83.3 lpm
	13.5 gpm (transmission) 51.1 lpm
Total flow	45 gpm 170.3 lpm
Steering flow	9.5 gpm 36.0 lpm

Tractor hitch
Rear Type	III/II
Rear lift (at 24"/610mm)	8,200 lbs 3719 kg

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	1000

Dimensions & Tires
Wheelbase	106 inches 269 cm
Weight	16850 to 17300 pounds
Front tire	10.00-16
Rear tire	18.4-38
Full dimensions and tires ...

Electrical
Charging system	alternator
Charging amps	100
Battery volts	12

Engine

Series map: 9170↑ 1989-1990805080706080169.3hp*189.7hp*93.0hp*8070↓ 1982-1985*Estimated engine power for comparison only.

Note: the Deutz-Allis model 8070 is the same as the Allis Chalmers 8070. The following data is from the 8070 listing.

Engine Detail — 426 ci / 7.0 L Diesel

Manufacturer	Allis Chalmers 670I
Configuration	turbocharged intercooled diesel, 6-cylinder, liquid-cooled inline
Displacement	426 ci 7.0 L
Bore/Stroke	4.25x5.00 inches 108 x 127 mm
Air cleaner	dry
Compression	15.5:1
Rated RPM	2400
Starter volts	12
Oil capacity	19 qts 18.0 L
	21 qts (3 filter) 19.9 L
Coolant capacity	36 qts 34.1 L

Transmission

Series map: 9170↑ 1989-1990805080706080169.3hp*189.7hp*93.0hp*8070↓ 1982-1985*Estimated engine power for comparison only.

Note: the Deutz-Allis model 8070 is the same as the Allis Chalmers 8070. The following data is from the 8070 listing.

Transmission options
20-speed partial power shift
12-speed Allis-Chalmers

Transmission — Allis-Chalmers Power Director

Transmission	Allis-Chalmers Power Director
Type	partial power shift
Gears	20 forward and 4 reverse
Oil capacity	29.6 qts 28.0 L
Five gears (1-5) in two ranges (slow/fast) with a two-speed power shift (low/high) controlled by left-hand lever.
With 18.4x38 rear tires.

Transmission — Power Shift

Transmission	Power Shift
Type	Allis-Chalmers
Gears	12 forward and 2 reverse
Oil capacity	29.6 qts 28.0 L
Six power shift gears (1-6) in two ranges (slow/fast). Clutch must be used to shift range. Pressing the clutch pedal half-way automatically downshifts from 5th/6th to 4th gear.
With 18.4x38 rear tires.

Dimensions

Series map: 9170↑ 1989-1990805080706080169.3hp*189.7hp*93.0hp*8070↓ 1982-1985*Estimated engine power for comparison only.

Note: the Deutz-Allis model 8070 is the same as the Allis Chalmers 8070. The following data is from the 8070 listing.

Deutz-Allis 8070 Tires
Ag front	10.00-16 (2WD)
	13.6-28 (4WD)
Ag rear	18.4-38
Ag front	11.00-16 (2WD)
	14L-16 (2WD)
	18.4-16 (2WD)
	14.9-28 (4WD)
	14.9-24 (4WD)
Ag rear	20.8-38
	18.4-42
	16.9-38

Dimensions
Wheelbase	106 inches 269 cm
Length	187 inches 474 cm
Width	95.5 inches 242 cm
	119.5 inches (long axle) 303 cm
Ground clearance	22 inches (front axle) 55 cm
	29 inches (rear axle) 73 cm

Deutz-Allis 8070 Weight
Operating	16,850 lbs (2WD duals) 7643 kg
	17,300 lbs (4WD) 7847 kg
Ballasted	22,370 lbs 10147 kg

Deutz-Allis 8070 Height
Hood	70 inches 177 cm
Cab	116 inches 294 cm
Exhaust	114 inches 289 cm

Tests

Series map: 9170↑ 1989-1990805080706080169.3hp*189.7hp*93.0hp*8070↓ 1982-1985*Estimated engine power for comparison only.

Note: the Deutz-Allis model 8070 is the same as the Allis Chalmers 8070. The following data is from the 8070 listing.

Nebraska Tractor Test 1449
Diesel 12-speed 2WD September 1 - 16, 1982 Link: Nebraska Tractor Test 1449 file
PTO performance
Power at rated engine speed	170.72 hp 127.3 kW
Fuel use	10.7 gal/hour 40.5 l/hour
Power at rated PTO speed	171.44 hp 127.8 kW
Fuel use	10.4 gal/hour 39.4 l/hour
Drawbar performance
Max power	145.36 hp 108.4 kW
Gear 2F used for power test.
Max pull	18,777 lbs 8517 kg
Gear 2S used for pull test.

Photos

Deutz-Allis 8070 tractor photo
