Deutz-Fahr Agroplus 70

The Deutz-Fahr Agroplus 70 is a tractor produced by Deutz Fahr. It is equipped with a 249.27 ci 4.1 L engine. The listed engine power is Diesel (listed): 70 hp / 52.2 kW. Transmission: Synchrosplit. Operating weight: 6063 to 6835 pounds.

Engine Power

Diesel (listed): 70 hp / 52.2 kW

Fuel & Capacities

23.8 gal 90.1 L

Transmission

Synchrosplit

Operating Weight

6063 to 6835 pounds

Overview

	2001 - 2004 Agroplus SeriesUtility tractor Agroplus Series Utility tractor

Production
Manufacturer	Deutz-Fahr
Utility tractor

Deutz-Fahr Agroplus 70 Engine
Deutz 4.1L 4-cyl diesel
Fuel tank	23.8 gal 90.1 L
Engine details ...

Deutz-Fahr Agroplus 70 Power
Engine	70 hp 52.2 kW

Mechanical
Two- or four-wheel drive
Power steering
Wet disc brakes
Two-post ROPS in select markets. Deluxe and low-profile cabs available with optional air-conditioning.

Hydraulics
Type	open center
Valves	3
Pump flow	12.7 gpm 48.1 lpm

Tractor hitch
Rear Type	II
Rear lift	6393 lbs 2899 kg
Front Hitch	II
Front lift	3858 lbs 1749 kg

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	540/1000
Front PTO	independent
Front PTO Type	1000

Dimensions & Tires
Wheelbase	90.2 inches 229 cm
Weight	6063 to 6835 pounds
Front tire	7.50-18
Rear tire	11.52R24
Full dimensions and tires ...

References

Agroplus published in 1996, by Deutz-Fahr
Agroplus 60 70 published in 2002, by Deutz-Fahr

Engine

Engine Detail — 249.27 ci / 4.1 L Diesel

Manufacturer	Deutz F4L913
Fuel Type	Diesel
Configuration	4-cylinder, air-cooled
Displacement	249.27 ci 4.1 L
Bore/Stroke	3.94x4.84 inches 100 x 123 mm
Power	70 hp 52.2 kW
Rated RPM	2300

Transmission

Transmission options
30-speed
45-speed three-speed power shift

Transmission — Synchrosplit

Transmission	Synchrosplit
Gears	30 forward and 15 reverse

Transmission — 45 forward and reverse three-speed power shift

Type	three-speed power shift
Gears	45 forward and reverse

Dimensions

Deutz-Fahr Agroplus 70 Tires
Ag front	7.50-18
	11.2R24 (4WD)
Ag rear	11.52R24
	16.9R30 (4WD)

Dimensions
Wheelbase	90.2 inches 229 cm
Length	156.30 inches 397 cm
Height	96.85 inches 245 cm
2WD Weight	6063 lbs 2750 kg
4WD Weight	6835 lbs 3100 kg

Photos

Deutz-Fahr Agroplus 70 tractor photo

Recommended Implements & Sizing Guide

Engineering recommendations for Deutz Fahr Deutz-Fahr Agroplus 70 based on its 70 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	3 to 4 Bottom (16")3 - 4 铧 (40 cm)	Heavy Duty	Suitable for medium loam and stubble turnover.
Rotary Cutter / MowerMowing & Clearing	7 to 8 ft (84-96 in)2.1 - 2.4 m	Heavy Duty	Heavy-duty twin spindle cutter for overgrown acreage.
Rotary TillerSeedbed Prep	78 to 84 in200 - 215 cm	Heavy Duty	Heavy commercial tiller with multi-speed gearbox.
Disc HarrowSecondary Tillage	7 to 8 ft Tandem Disc2.1 - 2.4 m 对开双排耙	Medium Duty	Field leveling and clod breaking behind plows.
Hay BalerHay & Forage	4x4 to 4x5 Round Baler1.2x1.5 m 紧凑圆捆机	Heavy Duty	Silage and dry hay; 540 RPM PTO with slip-clutch.

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Deutz Fahr Deutz-Fahr Agroplus 70.

Estimated Continuous Field Runtime: 6.5 hrs

Approximately 6.5 hours of continuous field operation at ~75% rated power on a full tank (23.8 gal / 90.1 L).

Estimated 75% Load Fuel Burn~3.6 gal/hr (13.8 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours

Deutz Fahr Deutz-Fahr Agroplus 70 Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Deutz Fahr Deutz-Fahr Agroplus 70.

Enter value:

Unit:

Converted Equivalents:

Horsepower (HP)70 hp

Kilowatts (kW)52.2 kW

Metric Horsepower (PS / CV)71 PS
