Hurlimann Prince 325

The Hurlimann Prince 325 is a tractor produced by Hurlimann. It is equipped with a 68.2 ci 1.1 L engine. The listed engine power is Diesel (listed): 25 hp / 18.6 kW. Transmission: 12 forward and reverse. Operating weight: 2,215 lbs 1004 kg.

Engine Power

Diesel (listed): 25 hp / 18.6 kW

Fuel & Capacities

7.7 gal 29.1 L

Transmission

12 forward and reverse

Operating Weight

2,215 lbs 1004 kg

Overview

	1999 - 2003 Prince SeriesCompact Utility tractor Prince Series Compact Utility tractor

Series map: Prince 325Prince 43525.0hp35.0hp

Note: the Hurlimann model Prince 325 is the same as the SAME Solaris 25. The following data is from the Solaris 25 listing.

Production
Manufacturer	Hurlimann
Compact Utility tractor
Original price	$16,000 (1999)

Hurlimann Prince 325 Engine
Mitsubishi 1.1L 3-cyl diesel
Fuel tank	7.7 gal 29.1 L
Engine details ...

Hurlimann Prince 325 Transmission
12-speed synchronized shuttle
Transmission details ...

Hurlimann Prince 325 Power
Engine	25 hp 18.6 kW
PTO (claimed)	18.5 hp 13.8 kW

Mechanical
Four-wheel drive
Steering	hydrostatic power
Mechanical wet disc brakes
Two-post ROPS. Cab optional.

Hydraulics
Valves	1 (4 optional)
Pump flow	5.8 gpm 22.0 lpm

Tractor hitch
Rear Type	1
Control	position and draft control
Rear lift	2,645 lbs 1199 kg
Front Hitch	1 (optional)
Front lift	882 lbs 400 kg

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	540/1000
Mid PTO	optional
Front PTO	optional

Dimensions & Tires
Wheelbase	60.63 inches 154 cm
Weight	2,215 lbs 1004 kg
Front tire	6.50/80-12
Rear tire	250/80-18
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

Engine

Series map: Prince 325Prince 43525.0hp35.0hp

Note: the Hurlimann model Prince 325 is the same as the SAME Solaris 25. The following data is from the Solaris 25 listing.

Engine Detail — 68.2 ci / 1.1 L Diesel

Manufacturer	Mitsubishi K3F-D
Fuel Type	Diesel
Configuration	3-cylinder, liquid-cooled inline
Displacement	68.2 ci 1.1 L
Bore/Stroke	3.071x3.071 inches 78 x 78 mm
Power	25 hp 18.6 kW
Fuel system	direct injection
Air cleaner	dry
Rated RPM	3000
Starter volts	12

Transmission

Series map: Prince 325Prince 43525.0hp35.0hp

Note: the Hurlimann model Prince 325 is the same as the SAME Solaris 25. The following data is from the Solaris 25 listing.

Transmission — 12 forward and reverse synchronized shuttle

Type	synchronized shuttle
Gears	12 forward and reverse
Four gears (1-4) in three ranges with reverser.

Dimensions

Series map: Prince 325Prince 43525.0hp35.0hp

Note: the Hurlimann model Prince 325 is the same as the SAME Solaris 25. The following data is from the Solaris 25 listing.

Hurlimann Prince 325 Tires
Ag front	6.50/80-12
Ag rear	250/80-18

Dimensions
Wheelbase	60.63 inches 154 cm
Length	105.91 inches 269 cm
Width	44.13 inches (min) 112 cm
	50.43 inches (max) 128 cm
Weight	2,215 lbs 1004 kg
Ground clearance	11.42 inches 29 cm
Front tread	32.31 to 40.98 inches 82 to 104 cm
Rear tread	31.91 to 39.79 inches 81 to 101 cm

Hurlimann Prince 325 Height
Steering wheel	48.26 inches 122 cm
Hood	44.52 inches 113 cm
Cab	78.8 inches 200 cm

Photos

Hurlimann Prince 325

Hurlimann Prince 325 operator station.

Recommended Implements & Sizing Guide

Engineering recommendations for Hurlimann Prince 325 based on its 25 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	1 to 2 Bottom (12")1 - 2 铧 (30 cm)	Light Duty	Ideal for garden plots and light sandy soil.
Rotary Cutter / MowerMowing & Clearing	5 ft (60 in)1.5 m	Medium Duty	Pasture maintenance and weeds up to 1.5" diameter.
Rotary TillerSeedbed Prep	54 to 60 in135 - 150 cm	Medium Duty	Thorough seedbed preparation in orchards and vegetable plots.
Disc HarrowSecondary Tillage	5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片)	Light Duty	Small acreage soil break-up and secondary aeration.

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Hurlimann Prince 325.

Estimated Continuous Field Runtime: 5.9 hrs

Approximately 5.9 hours of continuous field operation at ~75% rated power on a full tank (7.7 gal / 29.1 L).

Estimated 75% Load Fuel Burn~1.3 gal/hr (4.9 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours
