Iseki TA545

The Iseki TA545 is a tractor produced by Iseki. It is equipped with a 152.5 ci 2.5 L engine. The rated power output is 45 hp 33.6 kW. Transmission: 16 forward and reverse. Operating weight: 3880 lbs 1759 kg.

Overview

	1993 - 1999 TA500 SeriesCompact Utility tractor
1993 - 1999
TA500 Series
Compact Utility tractor

1993 - 1999
TA500 Series
Compact Utility tractor

Production
Manufacturer	Iseki
Compact Utility tractor
Built in Japan

Iseki TA545 Engine
Isuzu 2.5L 4-cyl diesel
Fuel tank	13.5 gal 51.1 L
Engine details ...

Iseki TA545 Transmission
16-speed shuttle
Transmission details ...

Iseki TA545 Power
Engine	45 hp 33.6 kW

Mechanical
Two- or four-wheel drive
Power steering
Mechanical wet disc brakes
Two-post folding ROPS. Cab available with air-conditioning.

Hydraulics
Pressure	2400 psi 165.5 bar
Total flow	8.4 gpm 31.8 lpm
Steering flow	6 gpm 22.7 lpm

Tractor hitch
Rear Type	II
Rear lift (at ends)	4189 lbs 1900 kg

Power Take-off (PTO)
Rear PTO	independent
Clutch	electro-hydraulic
Rear PTO Type	540/1000

Dimensions & Tires
Wheelbase	77.6 inches 197 cm
Weight	3880 lbs 1759 kg
Front tire	7.5x16
2WD Rear tire	14.9x28
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	45
Battery volts	12
Battery AH	110

References
TA Series published in 1993, by Iseki

Engine

	1993 - 1999 TA500 SeriesCompact Utility tractor
1993 - 1999
TA500 Series
Compact Utility tractor

1993 - 1999
TA500 Series
Compact Utility tractor

Engine Detail
Isuzu 4JA1
diesel
4-cylinder
liquid-cooled
Displacement	152.5 ci 2.5 L
Bore/Stroke	3.66x3.62 inches 93 x 92 mm
Power	45 hp 33.6 kW
Rated RPM	2500
Torque	112.1 lb-ft 152.0 Nm
Torque RPM	1600
Starter	electric
Starter volts	12
Oil capacity	6.3 qts 6.0 L
Exhaust valve clearance	0.016 inches 0.406 mm

Transmission

	1993 - 1999 TA500 SeriesCompact Utility tractor
1993 - 1999
TA500 Series
Compact Utility tractor

1993 - 1999
TA500 Series
Compact Utility tractor

Transmission
Type	shuttle
Gears	16 forward and reverse
Oil capacity	33.8 qts 32.0 L

Dimensions

	1993 - 1999 TA500 SeriesCompact Utility tractor
1993 - 1999
TA500 Series
Compact Utility tractor

1993 - 1999
TA500 Series
Compact Utility tractor

Iseki TA545 Tires
2WD Standard tires (ag)	Front: 7.5x16. Rear: 14.9x28
4WD Standard tires (ag)	Front: 8.3x20. Rear: 14.9x28

Dimensions
Wheelbase	77.6 inches 197 cm
Length	134.3 inches 341 cm
Width	60.8 inches 154 cm
Height	63.6 inches 161 cm
Height (cab)	93.9 inches 238 cm
Weight	3880 lbs 1759 kg
Ground clearance	14.2 inches 36 cm
Front tread	48 to 61.4 inches 121 to 155 cm
Rear tread	48 to 63.8 inches 121 to 162 cm

Photos

Iseki TA545 tractor photo
