John Deere Z655
The John Deere Z655 is a tractor produced by John Deere Lawn Tractors. It is equipped with a 724 cc 44.2 ci engine. The rated power output is 27 hp 20.1 kW. Transmission: Tuff Torq TZT 7-D. Operating weight: 755 lbs 342 kg.
Engine Power
27 hp
20.1 kW
Fuel & Capacities
3.5 gal
13.2 L
Transmission
Tuff Torq TZT 7-D
Operating Weight
755 lbs
342 kg
John Deere Lawn Tractors John Deere Z655 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2011 - 2015
Model year 2011-20132014-2015
EZTrak Z600 SeriesZero-turn mower |
|---|---|
2011 - 2015 | |
Model year 2011-20132014-2015 | |
EZTrak Z600 Series | |
Zero-turn mower | |
2011 - 2015 | |
|---|---|
Model year 2011-20132014-2015 | |
EZTrak Z600 Series | |
Zero-turn mower |
Production | |
|---|---|
Manufacturer | John Deere |
Zero-turn mower | |
Built in Horicon, Wisconsin, USA | |
Original price was $5,899 in 2012 | |
John Deere Z655 Engine | |
|---|---|
27HP Briggs & Stratton 724cc 2-cyl gasoline | |
Fuel tank | 3.5 gal
13.2 L |
Engine details ...  | |
John Deere Z655 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Power steering | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Wheelbase | 48 inches
121 cm |
Weight | 755 lbs
342 kg |
Front tire | 13x6.5-6 |
Rear tire | 23x10.50-12 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery CCA | 195 |
Battery volts | 12 |
References | |
|---|---|
 | |
Operator's Manual EZtrak (OMM166321) published in 2012 | |
Residential Zero-Turn-Radius EZTrak Mowers published in 2013, by John Deere |
Engine
| 2011 - 2015
Model year 2011-20132014-2015
EZTrak Z600 SeriesZero-turn mower |
|---|---|
2011 - 2015 | |
Model year 2011-20132014-2015 | |
EZTrak Z600 Series | |
Zero-turn mower | |
2011 - 2015 | |
|---|---|
Model year 2011-20132014-2015 | |
EZTrak Z600 Series | |
Zero-turn mower |
Engine Detail — 724 cc / 44.2 ci Gasoline
Manufacturer | Briggs & Stratton 44 |
Fuel Type | Gasoline |
Configuration | 2-cylinder, air-cooled vertical-shaft V-Twin |
Displacement | 724 cc
44.2 ci |
Bore/Stroke | 3.12x2.89 inches
79 x 73 mm |
Power | 27 hp
20.1 kW |
Starter | electric |
Starter volts | 12 |
Transmission
| 2011 - 2015
Model year 2011-20132014-2015
EZTrak Z600 SeriesZero-turn mower |
|---|---|
2011 - 2015 | |
Model year 2011-20132014-2015 | |
EZTrak Z600 Series | |
Zero-turn mower | |
2011 - 2015 | |
|---|---|
Model year 2011-20132014-2015 | |
EZTrak Z600 Series | |
Zero-turn mower |
Transmission — Tuff Torq TZT 7-D
Transmission | Tuff Torq TZT 7-D |
Type | hydrostatic |
Gears | infinite forward and reverse |
 | |
Dimensions
| 2011 - 2015
Model year 2011-20132014-2015
EZTrak Z600 SeriesZero-turn mower |
|---|---|
2011 - 2015 | |
Model year 2011-20132014-2015 | |
EZTrak Z600 Series | |
Zero-turn mower | |
2011 - 2015 | |
|---|---|
Model year 2011-20132014-2015 | |
EZTrak Z600 Series | |
Zero-turn mower |
John Deere Z655 Tires | |
|---|---|
Lawn/turf front | 13x6.5-6 |
Lawn/turf rear | 23x10.50-12 |
Dimensions | |
|---|---|
Wheelbase | 48 inches
121 cm |
Length | 74.7 inches
189 cm |
Height | 45.3 inches
115 cm |
Weight | 755 lbs
342 kg |
Attachments
| 2011 - 2015
Model year 2011-20132014-2015
EZTrak Z600 SeriesZero-turn mower |
|---|---|
2011 - 2015 | |
Model year 2011-20132014-2015 | |
EZTrak Z600 Series | |
Zero-turn mower | |
2011 - 2015 | |
|---|---|
Model year 2011-20132014-2015 | |
EZTrak Z600 Series | |
Zero-turn mower |
54" Mower deck | |
|---|---|
Type | mid-mount John Deere |
3-blade | |
Cutting width | 54 inches
137 cm |
Cut height | 1 to 4 inch
2 to 10 cm |
Photos
John Deere Z655 zero-turn mower.
