John Deere Z930M EFI

The John Deere Z930M EFI is a tractor produced by John Deere Lawn Tractors. It is equipped with a 747 cc 45.6 ci engine. The listed engine power is Gasoline (gross): 26.5 hp / 19.8 kW. Transmission: Tuff Torq. Operating weight: 1365 lbs 619 kg.

Engine Power

Gasoline (gross): 26.5 hp / 19.8 kW

Fuel & Capacities

11.5 gal 43.5 L

Transmission

Tuff Torq

Operating Weight

1365 lbs 619 kg

Overview

	2013 - 2017 Z900 SeriesZero-turn mower Z900 Series Zero-turn mower

Production
Manufacturer	John Deere
Zero-turn mower
Built in Fuquay-Varina, North Carolina, USA

John Deere Z930M EFI Engine
26.5HP Kohler 747cc 2-cyl gasoline
Fuel tank	11.5 gal 43.5 L
Engine details ...

John Deere Z930M EFI Transmission
hydrostatic
Transmission details ...

Mechanical
Two-wheel drive
Power steering
Wet disc brakes
Two-post folding ROPS.

Power Take-off (PTO)
Mid PTO	independent
Clutch	electro-magnetic

Dimensions & Tires
Weight	1365 lbs 619 kg
Front tire	13x5-6
Rear tire	24x12-12
Full dimensions and tires ...

Electrical
Ground	negative
Charging amps	20
Battery volts	12

References

Commercial Mowers published in 2015, by John Deere

Engine

Engine Detail — 747 cc / 45.6 ci Gasoline

Manufacturer	Kohler ECV749
Fuel Type	Gasoline
Configuration	2-cylinder, air-cooled vertical-shaft V-Twin
Displacement	747 cc 45.6 ci
Bore/Stroke	3.27x2.72 inches 83 x 69 mm
Power (gross)	26.5 hp 19.8 kW
Fuel system	electronic fuel injection
Starter	electric
Starter volts	12

Transmission

Transmission — Tuff Torq

Transmission	Tuff Torq
Type	hydrostatic
Gears	infinite forward and reverse
Oil capacity	5.9 qts 5.6 L

Dimensions

John Deere Z930M EFI Tires
Lawn/turf front	13x5-6
Lawn/turf rear	24x12-12

Dimensions
Length	84 inches 213 cm
Height (ROPS)	73 inches 185 cm
Height (Folded ROPS)	47 inches 119 cm
Weight	1365 lbs 619 kg

Attachments

Attachment overview
54" mid-mount mower deck
60" mid-mount mower deck

Photos

John Deere Z930M EFI tractor photo

Recommended Implements & Sizing Guide

Engineering recommendations for John Deere Lawn Tractors John Deere Z930M EFI based on its 26.5 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	1 to 2 Bottom (12")1 - 2 铧 (30 cm)	Light Duty	Ideal for garden plots and light sandy soil.
Rotary Cutter / MowerMowing & Clearing	5 ft (60 in)1.5 m	Medium Duty	Pasture maintenance and weeds up to 1.5" diameter.
Rotary TillerSeedbed Prep	54 to 60 in135 - 150 cm	Medium Duty	Thorough seedbed preparation in orchards and vegetable plots.
Disc HarrowSecondary Tillage	5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片)	Light Duty	Small acreage soil break-up and secondary aeration.

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for John Deere Lawn Tractors John Deere Z930M EFI.

Estimated Continuous Field Runtime: 8.3 hrs

Approximately 8.3 hours of continuous field operation at ~75% rated power on a full tank (11.5 gal / 43.5 L).

Estimated 75% Load Fuel Burn~1.4 gal/hr (5.2 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours

John Deere Lawn Tractors John Deere Z930M EFI Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for John Deere Lawn Tractors John Deere Z930M EFI.

Enter value:

Unit:

Converted Equivalents:

Horsepower (HP)26.5 hp

Kilowatts (kW)19.8 kW

Metric Horsepower (PS / CV)26.9 PS
