Kubota B7800

The Kubota B7800 is a tractor produced by Kubota. It is equipped with a 91.5 ci 1.5 L engine. The rated power output is 30 hp 22.4 kW. Transmission: infinite forward and reverse (3-range). Operating weight: 890 lbs 403 kg.

Overview

	2003 - 2008 B SeriesCompact Utility tractor
2003 - 2008
B Series
Compact Utility tractor

Production
Manufacturer	Kubota
Compact Utility tractor

Variants
B2910	deluxe
B7800	economy

Kubota B7800 Engine
Kubota 1.5L 4-cyl diesel
Fuel tank	6.9 gal 26.1 L
Engine details ...

Kubota B7800 Transmission
hydrostatic
Transmission details ...

Kubota B7800 Power
Engine (gross)	30 hp 22.4 kW
PTO (claimed)	22 hp 16.4 kW

Mechanical
Four-wheel drive
Final drives	spur gear
Differential lock	mechanical rear
Power steering
Wet disc brakes
Two-post fixed ROPS. Folding ROPS optional.

Hydraulics
Type	open center
Pump flow	6.4 gpm 24.2 lpm
Total flow	9.5 gpm 36.0 lpm
Steering flow	3.1 gpm 11.7 lpm

Tractor hitch
Rear Type	I
Control	quarter-inching valve
Rear lift (at ends)	1655 lbs 750 kg
Rear lift (at 24"/610mm)	1300 lbs 589 kg

Power Take-off (PTO)
Rear PTO	live
Rear PTO Type	540 (1.375)
Engine RPM	540@2600
Mid PTO	live *Mid PTO standard with folding ROPS, optional with fixed ROPS.
Mid PTO Type	2500 (Kubota 10-spline)
Engine RPM	2500@2578

Dimensions & Tires
Wheelbase	65.6 inches 166 cm
Weight	1741 lbs 789 kg
Front tire	7-12
Rear tire	12.4-16
Full dimensions and tires ...

Electrical
Ground	negative
Battery CCA	443
Battery volts	12

References
B7400/B7500/B7800 B2410/B2710/B2910 published in 2003, by Kubota
B Series Standard, Deluxe and Premier Tractors published in 2004, by Kubota
B Series Standard and Premier Tractors published in 2007, by Kubota
B2710-B2910-B7800 (6C170-6311-3) published in 2003

Engine

Engine Detail — 91.5 ci / 1.5 L Diesel

Manufacturer	Kubota V1505-E-D16
Fuel Type	Diesel
Configuration	4-cylinder, liquid-cooled inline
Displacement	91.5 ci 1.5 L
Bore/Stroke	3.07x3.09 inches 78 x 78 mm
Power (gross)	30 hp 22.4 kW
Air cleaner	dry
Rated RPM	2600
Starter volts	12
Oil capacity	4.3 qts 4.1 L
Coolant capacity	4.7 qts 4.4 L

Transmission

Transmission — infinite forward and reverse (3-range) hydrostatic

Type	hydrostatic
Gears	infinite forward and reverse (3-range)
Oil capacity	15.3 qts 14.5 L
With 12.4-16 R1 rear tires.

Dimensions

Kubota B7800 Tires
Ag front	7-12
Ag rear	12.4-16
Lawn/turf front	24x8.50-14
Lawn/turf rear	13.6-16
Industrial front	23x8.50-14
Industrial rear	12.4-16

Dimensions
Wheelbase	65.6 inches 166 cm
Length	99.2 inches 251 cm
Width	53.8 inches 136 cm
Height (ROPS)	78.5 inches 199 cm
Weight	1741 lbs 789 kg
Ground clearance	14.6 inches 37 cm

Attachments

Attachment overview
60" mid-mount mower deck
72" mid-mount mower deck
Snowblower
Blade
Front-end loader
Backhoe

Kubota B4672A Backhoe
Backhoe type	Kubota B4672A Backhoe
Weight	845 lbs 383 kg
Transport height	67.7 inches 171 cm
Digging depth	73.9 inches 187 cm
Reach from pivot	98.1 inches 249 cm
Loading height	65 inches 165 cm
Bucket Rotation	180°
Swing Arc	180°
Bucket force	2950 lbs 1338 kg
Dipperstick force	1740 lbs 789 kg

Kubota BL4690A Backhoe
Backhoe type	Kubota BL4690A Backhoe
Weight	890 lbs 403 kg
Transport height	76 inches 193 cm
Digging depth	90.2 inches 229 cm
Reach from pivot	116.5 inches 295 cm
Loading height	78.9 inches 200 cm
Bucket Rotation	180°
Swing Arc	180°
Bucket force	2950 lbs 1338 kg
Dipperstick force	1740 lbs 789 kg
