Kubota GL277

The Kubota GL277 is a tractor produced by Kubota. It is equipped with a 91.5 ci 1.5 L engine. The rated power output is 26.7 hp 19.9 kW. Transmission: 16 forward and reverse. Operating weight: 2601 to 3020 pounds.

Overview

	1996 - 2001 GL SeriesCompact Utility tractor
1996 - 2001
GL Series
Compact Utility tractor

Production
Manufacturer	Kubota
Compact Utility tractor

Kubota GL277 Engine
Kubota 1.5L 3-cyl diesel
Fuel tank	7.1 gal 26.9 L
Engine details ...

Kubota GL277 Transmission
16-speed power shift
Transmission details ...

Kubota GL277 Power
Engine	26.7 hp 19.9 kW
PTO (claimed)	26.2 hp 19.5 kW

Mechanical
Four-wheel drive
Power steering
Mechanical wet disc brakes
Two-post ROPS. Cab optional.

Hydraulics
Pump flow	6.1 gpm 23.1 lpm

Tractor hitch
Rear Type	JIS1
Rear lift	2083 lbs 944 kg

Power Take-off (PTO)
Rear PTO Type	540 (1.375)
Engine RPM	568@2600
	803@2600
	985@2600
	1304@2600
	-803@2600

Dimensions & Tires
Wheelbase	64.8 inches 164 cm
Weight	2601 to 3020 pounds
Front tire	7-16
Rear tire	11.2-24
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References
GL (T0270-1920-8) published in 1996

Engine

Engine Detail — 91.5 ci / 1.5 L Diesel

Manufacturer	Kubota D1503
Fuel Type	Diesel
Configuration	3-cylinder, liquid-cooled
Displacement	91.5 ci 1.5 L
Bore/Stroke	3.268x3.638 inches 83 x 92 mm
Power	26.7 hp 19.9 kW
Rated RPM	2600
Starter	electric
Starter volts	12

Transmission

Transmission — 16 forward and reverse power shift

Type	power shift
Gears	16 forward and reverse

Dimensions

Kubota GL277 Tires
Standard tires (ag)	Front: 7-16. Rear: 11.2-24

Dimensions
Wheelbase	64.8 inches 164 cm
Length	120.1 inches 305 cm
Width	52 inches 132 cm
Height (ROPS)	78.8 inches 200 cm
Height (cab)	83.1 inches 211 cm
ROPS Weight	2601 lbs 1179 kg
Cab Weight	3020 lbs 1369 kg
Ground clearance	13.6 inches 34 cm
Front tread	42.5 inches 107 cm
Rear tread	41.3 to 53 inches 104 to 134 cm

Photos

Kubota GL277 tractor photo
