Lamborghini 165 Racing

The Lamborghini 165 Racing is a tractor produced by Lamborghini. It is equipped with a 366.12 ci 6.0 L engine. The listed engine power is Diesel (listed): 163 hp / 121.5 kW. Transmission: 27 forward and reverse. Operating weight: 12853 lbs 5830 kg.

Engine Power

Diesel (listed): 163 hp / 121.5 kW

Fuel & Capacities

95.1 gal 360.0 L

Transmission

27 forward and reverse

Operating Weight

12853 lbs 5830 kg

Overview

	1991 - 2001 Racing SeriesRow-Crop tractor Racing Series Row-Crop tractor

Production
Manufacturer	Lamborghini
Row-Crop tractor

Variants
H-6165 Master	similar Hurlimann model

Lamborghini 165 Racing Engine
SLH 6.0L 6-cyl diesel
Fuel tank	95.1 gal 360.0 L
Engine details ...

Lamborghini 165 Racing Transmission
27-speed 9-speed power shift
Transmission details ...

Lamborghini 165 Racing Power
Engine	163 hp 121.5 kW

Mechanical
Four-wheel drive
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning.

Hydraulics
Pump flow	15.9 gpm 60.2 lpm

Tractor hitch
Rear lift	18963 lbs 8601 kg

Power Take-off (PTO)
Rear PTO	independent
Clutch	electro-hydraulic wet disc
Rear PTO Type	540/1000

Dimensions & Tires
Wheelbase	112.2 inches 284 cm
Weight	12853 lbs 5830 kg
Front tire	16.9R30
Rear tire	20.8R38
Full dimensions and tires ...

Engine

Engine Detail — 366.12 ci / 6.0 L Diesel

Manufacturer	SLH 1000.6
Configuration	turbocharged diesel, 6-cylinder, liquid-cooled
Displacement	366.12 ci 6.0 L
Bore/Stroke	4.13x4.55 inches 105 x 116 mm
Power	163 hp 121.5 kW
Rated RPM	2350
Torque	447.7 lb-ft 607.1 Nm
Torque RPM	1400
Starter type	electric

Transmission

Transmission — 27 forward and reverse 9-speed power shift

Type	9-speed power shift
Gears	27 forward and reverse
Clutch	electro-hydraulic wet disc
Nine power shift gears in three ranges. Synchronized shuttle.
With 20.8R38 rear tires and 40 KPH transmission option. Reverse speeds are 9% faster than forward.

Dimensions

Lamborghini 165 Racing Tires
Ag front	16.9R30
Ag rear	20.8R38

Dimensions
Wheelbase	112.2 inches 284 cm
Length	177.6 inches 451 cm
	187 inches (with hitch) 474 cm
Width	92.9 inches*Minimum width. 235 cm
Height (hood)	75.6 inches 192 cm
Height (cab)	114.2 inches 290 cm
Weight	12853 lbs 5830 kg
Ground clearance	20.3 inches 51 cm
Front tread	74.8 to 98.4 inches 189 to 249 cm
Rear tread	72.1 to 88.6 inches 183 to 225 cm

Photos

Lamborghini 165 Racing tractor photo

Recommended Implements & Sizing Guide

Engineering recommendations for Lamborghini 165 Racing based on its 163 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	5 to 7 Bottom (18")5 - 7 铧 (45 cm)	Commercial / Field Scale	Large acreage tillage; requires front ballast weights.
Rotary Cutter / MowerMowing & Clearing	15 to 20 ft Batwing4.6 - 6.1 m 宽幅折叠翼	Commercial / Field Scale	Large commercial field and roadside mowing operations.
Rotary TillerSeedbed Prep	90 to 120 in Heavy Duty230 - 300 cm 重型旋耕机	Commercial / Field Scale	Deep intensive seedbed preparation for commercial row crops.
Disc HarrowSecondary Tillage	15 to 22 ft Folding Disc4.5 - 6.7 m 折叠式圆盘耙	Commercial / Field Scale	Wide commercial field leveling; requires hydraulic remotes.
Hay BalerHay & Forage	Large Square Baler (3x4 or 4x4)大方捆商用打捆机 (1.2x1.2 m)	Commercial / Field Scale	High-capacity commercial forage harvesting (1000 RPM PTO).

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Lamborghini 165 Racing.

Estimated Continuous Field Runtime: 11.2 hrs

Approximately 11.2 hours of continuous field operation at ~75% rated power on a full tank (95.1 gal / 360 L).

Estimated 75% Load Fuel Burn~8.5 gal/hr (32.1 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours
