Massey Ferguson 1140

The Massey Ferguson 1140 is a tractor produced by Massey Ferguson. It is equipped with a 91.4 ci 1.5 L engine. The rated power output is 30 hp 22.4 kW. Transmission: 16 forward and reverse. Operating weight: 2590 to 2700 pounds.

Overview

	1991 - 1993 1100 SeriesCompact Utility tractorIseki built
1991 - 1993
1100 Series
Compact Utility tractor
Iseki built

1991 - 1993
1100 Series
Compact Utility tractor
Iseki built

Production
Distributor	Massey Ferguson
Manufacturer	Iseki
Compact Utility tractor
Original price was $13,200 in 1992

Massey Ferguson 1140 Engine
Isuzu 1.5L 3-cyl diesel
Engine details ...

Massey Ferguson 1140 Transmission
16-speed partially synchronized
Transmission details ...

Massey Ferguson 1140 Power
Engine	30 hp 22.4 kW
PTO (claimed)	26.2 hp 19.5 kW

Mechanical
Two- or four-wheel drive
Power steering
Mechanical wet disc brakes
Two-post fixed ROPS.

Capacity
Fuel	7.9 gal 29.9 L
Hydraulic system	6.6 gal 25.0 L
Steering	2.8 qts 2.6 L

Hydraulics
Type	open center
Capacity	6.6 gal 25.0 L
Pressure	2133 psi 147.1 bar
Valves	2 OptOptional
Pump flow	6.9 gpm 26.1 lpm
Steering cap.	2.8 qts 2.6 L

Tractor hitch
Rear Type	I
Control	position control
Rear lift (at ends)	2866 lbs 1300 kg
Rear lift (at 24"/610mm)	1785 lbs 809 kg

Power Take-off (PTO)
Rear PTO	independent
Clutch	electro-hydraulic
Rear PTO Type	540 (1.375)
Mid PTO	independent OptOptional
Mid PTO Type	1950 (1.00 15-spline)
Engine RPM	1960@2600

Dimensions & Tires
Wheelbase	67 inches 170 cm
Weight	2590 to 2700 pounds
Front tire	5.00x15
Rear tire	12.4x24 (2WD)
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	40
Battery CCA	670
Battery volts	12

References
1140/1145 30-35 Engine HP Compact Tractors published in 1991, by Massey Ferguson
1140 published in 1991, by Massey Ferguson

Engine

	1991 - 1993 1100 SeriesCompact Utility tractorIseki built
1991 - 1993
1100 Series
Compact Utility tractor
Iseki built

1991 - 1993
1100 Series
Compact Utility tractor
Iseki built

Engine Detail — 91.4 ci / 1.5 L Diesel

Manufacturer	Isuzu E3AD1
Fuel Type	Diesel
Configuration	3-cylinder, liquid-cooled inline
Displacement	91.4 ci 1.5 L
Bore/Stroke	3.385x3.385 inches 86 x 86 mm
Power	30 hp 22.4 kW
Fuel system	indirect injection
Air cleaner	dual dry element
Pre-heating	glow plugs
Rated RPM	2600
Torque	73 lb-ft 99.0 Nm
Torque RPM	1600
Firing order	1-3-2
Starter volts	12
Starter power	1.9 hp 1.4 kW
Oil capacity	5.1 qts 4.8 L
Coolant capacity	7.2 qts 6.8 L

Transmission

	1991 - 1993 1100 SeriesCompact Utility tractorIseki built
1991 - 1993
1100 Series
Compact Utility tractor
Iseki built

1991 - 1993
1100 Series
Compact Utility tractor
Iseki built

Transmission — 16 forward and reverse partially synchronized

Type	partially synchronized
Gears	16 forward and reverse
Clutch	225mm dry disc
Four gears (1-4) in four ranges (1-4) with synchronized shuttle shifting. Gears three and four are synchronized.
With 12.4-24 rear tires. Reverse speeds are about 5% slower than forward.

Dimensions

	1991 - 1993 1100 SeriesCompact Utility tractorIseki built
1991 - 1993
1100 Series
Compact Utility tractor
Iseki built

1991 - 1993
1100 Series
Compact Utility tractor
Iseki built

Massey Ferguson 1140 Tires
Standard tires (ag)	Front: 5.00x15. Rear: 12.4x24 (2WD)
	Front: 7x16. Rear: 12.4x24 (4WD)
Lawn/turf front	24x8.50-12 (2WD)
	212/80D-15 (4WD)
Lawn/turf rear	355/80D-20

Dimensions
Wheelbase	67 inches 170 cm
Length	121 inches 307 cm
Width	52.75 inches 133 cm
Height (ROPS)	82.5 inches 209 cm
2WD Operating weight	2590 lbs 1174 kg
4WD Operating weight	2700 lbs 1224 kg
Ground clearance	12 inches 30 cm
Front tread	40 to 41.8 inches 101 to 106 cm (2WD)
Front tread	42.1 inches 106 cm (4WD)
Rear tread	40 to 52.75 inches 101 to 133 cm

Attachments

	1991 - 1993 1100 SeriesCompact Utility tractorIseki built
1991 - 1993
1100 Series
Compact Utility tractor
Iseki built

1991 - 1993
1100 Series
Compact Utility tractor
Iseki built

Photos

Massey Ferguson 1140 tractor photo
