McCormick-Deering FU235
The McCormick-Deering FU235 is a tractor produced by Mccormick Deering. It is equipped with a 122.7 ci 2.0 L engine. The rated power output is 26 hp 19.4 kW. Transmission: 4 forward and 1 reverse. Operating weight: 3483 to 3571 pounds.
Engine Power
26 hp
19.4 kW
Fuel & Capacities
Diesel
Transmission
4 forward and 1 reverse
Operating Weight
3483 to 3571 pounds
Mccormick Deering McCormick-Deering FU235 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1957 - 1959
Utility tractor |
|---|---|
1957 - 1959 | |
Utility tractor | |
Production | |
|---|---|
Manufacturer | McCormick-Deering (a part of International Harvester) |
Utility tractor | |
Built in Saint Dizier, France | |
Variants | |
|---|---|
FU-235 | gas utility |
FU-235D | diesel utility |
F-235 | row-crop |
FV-235 | orchard |
McCormick-Deering FU235 Transmission | |
|---|---|
4-speed gear | |
Transmission details ...  |
McCormick-Deering FU235 Power | |
|---|---|
Engine | 26 hp
19.4 kW |
Mechanical | |
|---|---|
Two-wheel drive | |
Open operator station. |
Dimensions & Tires | |
|---|---|
Weight | 3483 to 3571 pounds |
Front tire | 5.00-15 |
Rear tire | 10-28 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
235 Utility published in 1958, by International Harvester |
Engine
Engine options | |
|---|---|
International Harvester 2.0L 4-cyl gasoline | |
International Harvester 2.0L 4-cyl diesel |
Engine Detail — 122.7 ci / 2.0 L Gasoline
Manufacturer | International Harvester FC-123 |
Fuel Type | Gasoline |
Configuration | 4-cylinder, liquid-cooled |
Displacement | 122.7 ci
2.0 L |
Bore/Stroke | 3.125x4.00 inches
79 x 102 mm |
Power | 26 hp
19.4 kW |
Rated RPM | 1650 |
Starter type | electric |
Oil capacity | 5 qts
4.7 L |
Engine Detail — 122.7 ci / 2.0 L Diesel
Manufacturer | International Harvester FD-123 |
Fuel Type | Diesel |
Configuration | 4-cylinder, liquid-cooled |
Displacement | 122.7 ci
2.0 L |
Bore/Stroke | 3.125x4.00 inches
79 x 102 mm |
Power | 26 hp
19.4 kW |
Rated RPM | 1650 |
Starter type | electric |
Oil capacity | 5 qts
4.7 L |
McCormick-Deering FU235 Engine | |
|---|---|
 |
Transmission
Transmission — 4 forward and 1 reverse gear
Type | gear |
Gears | 4 forward and 1 reverse |
Oil capacity | 19 qts
18.0 L |
Dimensions
McCormick-Deering FU235 Tires | |
|---|---|
Ag front | 5.00-15 |
Ag rear | 10-28 |
Dimensions | |
|---|---|
Length | 104.7 inches
265 cm |
Width | 68.5 inches*Minimum width.
173 cm |
Height (steering wheel) | 55.9 inches
141 cm |
Gas Weight | 3483 lbs
1579 kg |
Diesel Weight | 3571 lbs
1619 kg |
Ground clearance | 20.1 inches
51 cm |
Front tread | 49.2 to 75.2 inches
124 to 191 cm |
Rear tread | 44.5 to 70.5 inches
113 to 179 cm |
Photos
McCormick-Deering FU235
McCormick-Deering FU235
