TYM T224

The TYM T224 is a tractor produced by Tym. It is equipped with a 60.6 ci 1.0 L engine. The listed engine power is Diesel (gross): 21.5 hp / 16.0 kW. Transmission: infinite forward and reverse (2-range). Operating weight: 725 lbs*Weight without bucket. 328 kg.

Overview

	2020 - Compact Utility tractor
2020 -
Compact Utility tractor

Production
Manufacturer	TYM
Compact Utility tractor

TYM T224 Engine
Yanmar 1.0L 3-cyl diesel
Fuel tank	6.6 gal 25.0 L
Engine details ...

TYM T224 Transmission
hydrostatic
Transmission details ...

TYM T224 Power
Engine (gross)	21.5 hp 16.0 kW

Mechanical
Power steering
Wet disc brakes
Two-post folding ROPS.

Hydraulics
Type	open center
Pump flow	4.17 gpm 15.8 lpm
Total flow	6.97 gpm 26.4 lpm
Steering flow	2.11 gpm 8.0 lpm

Tractor hitch
Rear Type	I
Control	position control
Rear lift (at ends)	1100 lbs 498 kg
Rear lift (at 24"/610mm)	679 lbs 307 kg

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	540 (1.375)
Mid PTO	independent
Mid PTO Type	2500

Dimensions & Tires
Wheelbase	53.1 inches 134 cm
Weight	1433 lbs 650 kg
Front tire	16x7.50-9
Rear tire	24x12.00-12
Full dimensions and tires ...

Electrical
Ground	negative
Charging amps	40
Battery volts	12

References
Operator's Manual for Tractor T224 published in 2019

Engine

Engine Detail — 60.6 ci / 1.0 L Diesel

Manufacturer	Yanmar 3TNM74F
Fuel Type	Diesel
Configuration	3-cylinder, liquid-cooled
Displacement	60.6 ci 1.0 L
Bore/Stroke	2.91x3.03 inches 74 x 77 mm
Power (gross)	21.5 hp 16.0 kW
Fuel system	indirect injection
Air cleaner	dry
Rated RPM	3200
Starter	electric
Starter volts	12
Oil capacity	2.1 qts 2.0 L
Coolant capacity	3.7 qts 3.5 L

Transmission

Transmission — infinite forward and reverse (2-range) hydrostatic

Type	hydrostatic
Gears	infinite forward and reverse (2-range)
Oil capacity	14.3 qts 13.5 L

Dimensions

TYM T224 Tires
Standard tires (ag)	Front: 16x7.50-9. Rear: 24x12.00-12
Lawn/turf front	16x7.50-8
Lawn/turf rear	16x12.00-12

Dimensions
Wheelbase	53.1 inches 134 cm
Length	94.2 inches 239 cm
Width	44.5 inches 113 cm
Height (ROPS)	86.6 inches 219 cm
Weight	1433 lbs 650 kg
Ground clearance	8.3 inches 21 cm

Attachments

Attachment overview
48" mid-mount mower deck
54" mid-mount mower deck
Front-end loader
Backhoe

TYM BY60 Backhoe
Backhoe type	TYM BY60 Backhoe
Weight	725 lbs*Weight without bucket. 328 kg
Transport height	66 inches 167 cm
Bucket width	9 inches 22 cm
	12 inches 30 cm
	16 inches 40 cm
	18 inches 45 cm
2-Foot flat digging depth	77 inches 195 cm
Reach from pivot	98 inches 248 cm
Loading height	60 inches 152 cm
Bucket Rotation	185°
Swing Arc	140°
Bucket force	2050 lbs 929 kg
Dipperstick force	1256 lbs 569 kg

Photos

TYM T224 compact utility tractor with front-end loader.
