UTB/Universal 1010

The UTB/Universal 1010 is a tractor produced by Utb Universal. It is equipped with a 329.1 ci 5.4 L engine. The listed engine power is Diesel (listed): 100 hp / 74.6 kW. Transmission: 16 forward and 4 reverse. Operating weight: 9921 lbs 4500 kg.

Overview

	1984 - 1991 Row-Crop tractor

Production
Manufacturer	UTB/Universal
Row-Crop tractor
Built in Brasov, Romania
Original price was $36,000 in 1991

Variants
1010DT	4WD

UTB/Universal 1010 Engine
UTB 5.4L 6-cyl diesel
Fuel tank	45 gal 170.3 L
Engine details ...

UTB/Universal 1010 Transmission
16-speed
Transmission details ...

UTB/Universal 1010 Power
Engine	100 hp 74.6 kW

Mechanical
Two- or four-wheel drive

Hydraulics
Pump flow	8.2 gpm 31.0 lpm

Tractor hitch
Rear Type	II

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	540, 1000

Dimensions & Tires
Wheelbase	103 inches 261 cm
Weight	9921 lbs 4500 kg
Front tire	7.50-20
Rear tire	16.9-38
Full dimensions and tires ...

References
Loaders published in 1987, by Universal

Engine

Engine Detail — 329.1 ci / 5.4 L Diesel

Manufacturer	UTB
Fuel Type	Diesel
Configuration	6-cylinder, liquid-cooled
Displacement	329.1 ci 5.4 L
Bore/Stroke	4.016x4.331 inches 102 x 110 mm
Power	100 hp 74.6 kW
Rated RPM	2400

Transmission

Transmission — 16 forward and 4 reverse

Gears

16 forward and 4 reverse

Dimensions

UTB/Universal 1010 Tires
Ag front	7.50-20
Ag rear	16.9-38

Dimensions
Wheelbase	103 inches 261 cm
Weight	9921 lbs 4500 kg

Photos

UTB/Universal 1010
