CaseIH Luxxum 110
The CaseIH Luxxum 110 is a tractor produced by Caseih. It is equipped with a 207 ci 3.4 L engine. The rated power output is 107 hp 79.8 kW. Transmission: 32 forward and reverse. Operating weight: 9678 lbs 4389 kg.
Engine Power
107 hp
79.8 kW
Fuel & Capacities
39.6 gal
149.9 L
Transmission
32 forward and reverse
Operating Weight
9678 lbs
4389 kg
Caseih Luxxum 110 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2016 - 2025
Model year 2016-20222022-2025
Luxxum SeriesUtility tractor |
|---|---|
2016 - 2025 | |
Model year 2016-20222022-2025 | |
Luxxum Series | |
Utility tractor | |
Production | |
|---|---|
Manufacturer | CaseIH |
Utility tractor | |
Built in Saint Valentin, Austria | |
Variants | |
|---|---|
Farmall 110U | similar CaseIH model |
CaseIH Luxxum 110 Engine | |
|---|---|
FPT 3.4L 4-cyl diesel | |
Fuel tank | 39.6 gal
149.9 L |
Exhaust fluid (DEF) | 3.7 gal
14.0 L |
Engine details ...  | |
CaseIH Luxxum 110 Transmission | |
|---|---|
32-speed four-speed power shift | |
Transmission details ...  |
CaseIH Luxxum 110 Power | |
|---|---|
Engine (gross) | 107 hp
79.8 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Differential lock | electro-hydraulic front and rear |
Power steering | |
Wet disc brakes | |
Cab standard with air-conditioning. | |
Hydraulics | |
|---|---|
Type | closed center load sensing |
Rear valves | 4 OptOptional |
Mid valves | 2 OptOptional |
Pump flow | 21.1 gpm
79.9 lpm |
26.4 gpmOptOptional
99.9 lpm | |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/540E/1000/1000E |
Front PTO | independent |
Front PTO Type | 540/540E/1000/1000E |
Dimensions & Tires | |
|---|---|
Wheelbase | 95.3 inches
242 cm |
95.7 inches (suspended axle)
243 cm | |
Weight | 9678 lbs
4389 kg |
Front tire | 480/65R24 |
Rear tire | 540/65R38 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Charging system | alternator |
References | |
|---|---|
 | |
Luxxum published in 2016, by CaseIH |
Engine
Engine Detail — 207 ci / 3.4 L Diesel
Manufacturer | FPT |
Configuration | turbocharged diesel, 4-cylinder, liquid-cooled |
Displacement | 207 ci
3.4 L |
Bore/Stroke | 3.90x4.33 inches
99 x 110 mm |
Emissions | Stage IV |
Rated Power (gross) | 107 hp
79.8 kW |
Rated RPM | 2200 |
Torque | 348 lb-ft
471.9 Nm |
Torque RPM | 1500 |
Starter | electric |
Starter volts | 12 |
CaseIH Luxxum 110 Engine | |
|---|---|
 |
Transmission
Transmission — 32 forward and reverse four-speed power shift
Type | four-speed power shift |
Gears | 32 forward and reverse |
Dimensions
CaseIH Luxxum 110 Tires | |
|---|---|
Standard tires (ag) | Front: 480/65R24. Rear: 540/65R38 |
Dimensions | |
|---|---|
Wheelbase | 95.3 inches
242 cm |
95.7 inches (suspended axle)
243 cm | |
Length | 165.2 inches
419 cm |
Width | 82.7 inches
210 cm |
Height (cab) | 107.1 inches
272 cm |
Shipping weight | 9678 lbs
4389 kg |
Max weight | 17637 lbs
8000 kg |
Photos
CaseIH Luxxum 110 tractor photo
