CaseIH MX90C

The CaseIH MX90C is a tractor produced by Caseih. It is equipped with a 243.5 ci 4.0 L engine. The rated power output is 90 hp 67.1 kW. Transmission: 32 forward and 24 reverse. Operating weight: 10472 to 11200 pounds.

Overview

	1998 - 2002 Utility tractor
1998 - 2002
Utility tractor

Production
Manufacturer	CaseIH
Utility tractor
Built in Doncaster, England
Original price	$55,000 (1999)

CaseIH MX90C Engine
Perkins 4.0L 4-cyl diesel
Engine details ...

CaseIH MX90C Power
Engine	90 hp 67.1 kW
PTO (claimed)	74 hp 55.2 kW
Drawbar (tested)	63.3 hp 47.2 kW
PTO (tested)	75.5 hp 56.3 kW
Performance test details ...

Mechanical
Four-wheel drive
Steering	hydrostatic power
Differential hydraulic wet disc brakes
Cab standard.

Capacity
Fuel	50 gal 189.2 L
Hydraulic system	17.5 gal 66.2 L

Hydraulics
Type	closed center pressure-flow compensating (PFC)
Capacity	17.5 gal 66.2 L
Pressure	2950 psi 203.4 bar
Valves	2 to 4
Pump flow	25 gpm 94.6 lpm
Total flow	28.9 gpm 109.4 lpm

Tractor hitch
Rear Type	II
Control	electronic lower link
Rear lift (at 24"/610mm)	8,393 lbs 3807 kg

Power Take-off (PTO)
Rear PTO	independent
Clutch	electrically-actuated wet disc
Rear PTO Type	540/1000 (1.375)
Engine RPM	540@1875
	1000@2210

Dimensions & Tires
Wheelbase	95.4 inches 242 cm
Weight	10472 to 11200 pounds
Front tire	14.9R-24
Rear tire	18.4-34
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	95
Charging volts	12
Batteries	2
Battery CCA	700
Battery volts	12

References
MX Series Tractors published in 1998, by CaseIH

Engine

Engine Detail — 243.5 ci / 4.0 L Diesel

Manufacturer	Perkins
Configuration	turbocharged diesel, 4-cylinder, liquid-cooled
Displacement	243.5 ci 4.0 L
Bore/Stroke	3.937x5.00 inches 100 x 127 mm
Power	90 hp 67.1 kW
Fuel system	direct-injection with mechanical governor, rotary injection pump with 5-hole nozzles
Air cleaner	dual paper elements
Compression	17.25:1
Rated RPM	2200
Starter volts	12
Oil capacity	9.3 qts 8.8 L
Coolant capacity	16.6 qts 15.7 L

CaseIH MX90C Engine

Transmission

Transmission options
16-speed partial power shift
32-speed creeper

Transmission — 16 forward and 12 reverse partial power shift

Type	partial power shift
Gears	16 forward and 12 reverse
Clutch	hydraulic wet discs
Four power shift speeds (1-4) in four synchronized ranges (I-IV) with power shuttle. Three ranges in reverse.
Transmission
Type	creeper
Gears	32 forward and 24 reverse

Dimensions

CaseIH MX90C Tires
Ag front	14.9R-24
Ag rear	18.4-34

Dimensions
Wheelbase	95.4 inches 242 cm
Length	170.6 inches 433 cm
Height (cab)	110.3 inches 280 cm
Shipping weight	10,472 lbs 4750 kg
Operating weight	11,200 lbs 5080 kg

Tests

OCED Tractor Test 1929
Diesel 16-speed 4WD March 1 - May 1, 2000 Link: OCED Tractor Test 1929 file
PTO performance
Max power	75.5 hp 56.3 kW
Fuel use	5.0 gal/hour 18.9 l/hour
Power at rated engine speed	75.4 hp 56.2 kW
Fuel use	5.2 gal/hour 19.7 l/hour
Drawbar performance
Max power	63.3 hp 47.2 kW
Fuel use	5.2 gal/hour 19.7 l/hour
Gear 1-III used for power test.
Max pull	11,935 lbs 5413 kg
Gear 2-I used for pull test.
