Cub Cadet Recon 60

The Cub Cadet Recon 60 is a tractor produced by Cub Cadet Lawn Tractors. It is equipped with a 724 cc 44.2 ci engine. The listed engine power is Gasoline (gross): 25 hp / 18.6 kW. Transmission: Kanzaki DUP-10. Operating weight: 1035 lbs 469 kg.

Engine Power

Gasoline (gross): 25 hp / 18.6 kW

Fuel & Capacities

10 gal*Two 5-gallon tanks 37.9 L

Transmission

Kanzaki DUP-10

Operating Weight

1035 lbs 469 kg

Overview

	2008 - 2009 Recon SeriesZero-turn mower Recon Series Zero-turn mower

Production
Manufacturer	Cub Cadet (a part of MTD)
Zero-turn mower

Cub Cadet Recon 60 Engine
25HP Kohler 724cc 2-cyl gasoline
Fuel tank	10 gal*Two 5-gallon tanks 37.9 L
Engine details ...

Cub Cadet Recon 60 Transmission
hydrostatic
Transmission details ...

Mechanical
Two-wheel drive
Power steering
Two-post ROPS.

Power Take-off (PTO)
Mid PTO	independent
Clutch	electric

Dimensions & Tires
Wheelbase	44.5 inches 113 cm
Weight	1035 lbs 469 kg
Front tire	13x5-6
Rear tire	23x9.5-12
Full dimensions and tires ...

Electrical
Ground	negative
Charging amps	15
Battery volts	12

References

RECON Commercial Zero-Turn Mowers published in 2009, by Cub Cadet

Engine

Engine Detail — 724 cc / 44.2 ci Gasoline

Manufacturer	Kohler CV730
Fuel Type	Gasoline
Configuration	2-cylinder, air-cooled vertical-shaft V-Twin
Displacement	724 cc 44.2 ci
Bore/Stroke	3.3x2.6 inches 84 x 66 mm
Power (gross)	25 hp 18.6 kW
Starter	electric
Starter volts	12

Transmission

Transmission — Kanzaki DUP-10

Transmission	Kanzaki DUP-10
Type	hydrostatic
Gears	infinite forward and reverse

Dimensions

Cub Cadet Recon 60 Tires
Lawn/turf front	13x5-6
Lawn/turf rear	23x9.5-12

Dimensions
Wheelbase	44.5 inches 113 cm
Length	78 inches 198 cm
Width	71 inches 180 cm
Height	40.5 inches 102 cm
Weight	1035 lbs 469 kg
Front tread	40 inches 101 cm
Rear tread	46.5 inches 118 cm

Attachments

60" Mower deck
Type	mid-mount Cub Cadet
	3-blade
Cutting width	60 inches 152 cm
Cut height	1 to 5 inch 2 to 12 cm

Photos

Cub Cadet Recon 60 tractor photo

Recommended Implements & Sizing Guide

Engineering recommendations for Cub Cadet Lawn Tractors Cub Cadet Recon 60 based on its 25 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	1 to 2 Bottom (12")1 - 2 铧 (30 cm)	Light Duty	Ideal for garden plots and light sandy soil.
Rotary Cutter / MowerMowing & Clearing	5 ft (60 in)1.5 m	Medium Duty	Pasture maintenance and weeds up to 1.5" diameter.
Rotary TillerSeedbed Prep	54 to 60 in135 - 150 cm	Medium Duty	Thorough seedbed preparation in orchards and vegetable plots.
Disc HarrowSecondary Tillage	5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片)	Light Duty	Small acreage soil break-up and secondary aeration.

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Cub Cadet Lawn Tractors Cub Cadet Recon 60.

Estimated Continuous Field Runtime: 7.7 hrs

Approximately 7.7 hours of continuous field operation at ~75% rated power on a full tank (10 gal / 37.9 L).

Estimated 75% Load Fuel Burn~1.3 gal/hr (4.9 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours

Cub Cadet Lawn Tractors Cub Cadet Recon 60 Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Cub Cadet Lawn Tractors Cub Cadet Recon 60.

Enter value:

Unit:

Converted Equivalents:

Horsepower (HP)25 hp

Kilowatts (kW)18.6 kW

Metric Horsepower (PS / CV)25.3 PS

Direct Competitor Comparison

Compare Cub Cadet Recon 60 against same-era industry alternatives in the same horsepower class.
