Fendt F275GT
The Fendt F275GT is a tractor produced by Fendt. It is equipped with a 230 ci 3.8 L engine. The listed engine power is Diesel (listed): 70 hp / 52.2 kW. Transmission: 20 forward and 6 reverse. Operating weight: 8201 lbs 3719 kg.
Engine Power
Diesel (listed): 70 hp / 52.2 kW
Fuel & Capacities
21.1 gal
79.9 L
Transmission
20 forward and 6 reverse
Operating Weight
8201 lbs
3719 kg
Overview
 | 1976 - 1982
Tool Carrier tractor |
|---|
Production | |
|---|---|
Manufacturer | Fendt |
Tool Carrier tractor | |
Fendt F275GT Engine | |
|---|---|
KHD 3.8L 4-cyl diesel | |
Fuel tank | 21.1 gal
79.9 L |
Engine details ...  | |
Fendt F275GT Power | |
|---|---|
Engine | 70 hp
52.2 kW |
Mechanical | |
|---|---|
Two-wheel drive | |
Differential lock | mechanical rear |
Power steering | |
Hydraulic brakes | |
Cab standard | |
Hydraulics | |
|---|---|
Type | open center |
Pressure | 2538 psi
175.0 bar |
Pump flow | 10.6 gpm
40.1 lpm |
Tractor hitch | |
|---|---|
Rear lift | 6000 lbs
2721 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540/1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 123.2 inches
312 cm |
Weight | 8201 lbs
3719 kg |
Front tire | 7.50-16 |
Rear tire | 13.6-38 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Charging system | alternator |
Charging amps | 33 |
Charging volts | 14 |
Battery volts | 12 |
Battery AH | 110 |
References | |
|---|---|
 | |
Kommunal-System 255/275 GT published in 1982, by Fendt |
Engine
Engine Detail — 230 ci / 3.8 L Diesel
Manufacturer | KHD F4L915H |
Fuel Type | Diesel |
Configuration | 4-cylinder, air-cooled |
Displacement | 230 ci
3.8 L |
Bore/Stroke | 3.937x4.724 inches
100 x 120 mm |
Power | 70 hp
52.2 kW |
Fuel system | direct injection |
Rated RPM | 2300 |
Torque | 180.7 lb-ft
245.0 Nm |
Torque RPM | 1600 |
Starter volts | 12 |
Transmission
Transmission options | |
|---|---|
14-speed synchromesh | |
20-speed creeper |
Transmission — 14 forward and 4 reverse synchromesh
Type | synchromesh |
Gears | 14 forward and 4 reverse |
Clutch | mechanical dry disc |
With 16.9/14-34 rear tires. | |
 | |
Transmission | |
Type | creeper |
Gears | 20 forward and 6 reverse |
 | |
Dimensions
Fendt F275GT Tires | |
|---|---|
Ag front | 7.50-16 |
Ag rear | 13.6-38 |
Dimensions | |
|---|---|
Wheelbase | 123.2 inches
312 cm |
Length | 187.9 inches
477 cm |
Width | 74 inches
187 cm |
Height (cab) | 102.1 inches
259 cm |
Weight | 8201 lbs
3719 kg |
Ground clearance | 18.9 inches
48 cm |
Front tread | 53.5/59.1/64.6/66.9/70.9 inches
135/150/164/169/180 cm |
Rear tread | 59.1/64.6 inches
150/164 cm |
Photos
Fendt F275GT tractor photo
Recommended Implements & Sizing Guide
Engineering recommendations for Fendt F275GT based on its 70 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 3 to 4 Bottom (16")3 - 4 铧 (40 cm) | Heavy Duty | Suitable for medium loam and stubble turnover. |
Rotary Cutter / MowerMowing & Clearing | 7 to 8 ft (84-96 in)2.1 - 2.4 m | Heavy Duty | Heavy-duty twin spindle cutter for overgrown acreage. |
Rotary TillerSeedbed Prep | 78 to 84 in200 - 215 cm | Heavy Duty | Heavy commercial tiller with multi-speed gearbox. |
Disc HarrowSecondary Tillage | 7 to 8 ft Tandem Disc2.1 - 2.4 m 对开双排耙 | Medium Duty | Field leveling and clod breaking behind plows. |
Hay BalerHay & Forage | 4x4 to 4x5 Round Baler1.2x1.5 m 紧凑圆捆机 | Heavy Duty | Silage and dry hay; 540 RPM PTO with slip-clutch. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Fendt F275GT.
Estimated Continuous Field Runtime: 5.8 hrs
Approximately 5.8 hours of continuous field operation at ~75% rated power on a full tank (21.1 gal / 79.9 L).
Estimated 75% Load Fuel Burn~3.6 gal/hr (13.8 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Fendt F275GT Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Fendt F275GT.
Converted Equivalents:
Horsepower (HP)70 hp
Kilowatts (kW)52.2 kW
Metric Horsepower (PS / CV)71 PS
