Fendt Farmer 306LS

The Fendt Farmer 306LS is a tractor produced by Fendt. It is equipped with a 253.5 ci 4.2 L engine. The listed engine power is Diesel (listed): 70 hp / 52.2 kW. Transmission: 21 forward and 6 reverse. Operating weight: 7793 to 8168 pounds.

Engine Power

Diesel (listed): 70 hp / 52.2 kW

Fuel & Capacities

28.3 gal 107.1 L

Transmission

21 forward and 6 reverse

Operating Weight

7793 to 8168 pounds

Overview

	1980 - 1993 Farmer 300 SeriesRow-Crop tractor Farmer 300 Series Row-Crop tractor

Production
Manufacturer	Fendt
Row-Crop tractor

Fendt Farmer 306LS Engine
MWM 4.2L 4-cyl diesel
Fuel tank	28.3 gal 107.1 L
Engine details ...

Fendt Farmer 306LS Power
Engine	70 hp 52.2 kW

Mechanical
Two- or four-wheel drive
Power steering
Wet disc brakes
Cab standard with heat. Air-conditioning optional.

Hydraulics
Type	open center
Pump flow	10.0 gpm 37.9 lpm
Steering flow	8.7 gpm 32.9 lpm

Tractor hitch
Rear Type	II
Control	position and draft control
Rear lift	6107 lbs 2770 kg
Front Hitch	II OptOptional
Front lift	5534 lbs 2510 kg

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	540/1000
	540/750
	540/750/1000
Front PTO	independent
Front PTO Type	1000

Dimensions & Tires
2WD Wheelbase	91.3 inches 231 cm
4WD Wheelbase	77.6 inches 197 cm
Weight	7793 to 8168 pounds
Front tire	7.50-20
2WD Rear tire	16.9R34
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	33
	55 OptOptional
Battery volts	12
Battery AH	110

References

Innovations for 1988 published by Fendt

Engine

Engine Detail — 253.5 ci / 4.2 L Diesel

Manufacturer	MWM
Fuel Type	Diesel
Configuration	4-cylinder, liquid-cooled
Displacement	253.5 ci 4.2 L
Bore/Stroke	4.13x4.72 inches 105 x 120 mm
Power	70 hp 52.2 kW
Rated RPM	2200
Torque	197.7 lb-ft 268.1 Nm
Torque RPM	1500
Starter volts	12

Transmission

Transmission options
15-speed synchromesh
21-speed

Transmission — 15 forward and 4 reverse synchromesh

Type	synchromesh
Gears	15 forward and 4 reverse
Clutch	310mm hydraulic disc
Three gears (1-3), plus reverse (R), in two ranges (low/high) with two-speed torque converter (L/S). Additional three overdrive gears for road speed.

Transmission — 21 forward and 6 reverse

Gears	21 forward and 6 reverse
Three gears (1-3), plus reverse (R), in two ranges (low/high) with three-speed torque converter (L/M/S). Additional three overdrive gears for road speed.

Dimensions

Fendt Farmer 306LS Tires
2WD Standard tires (ag)	Front: 7.50-20. Rear: 16.9R34
4WD Standard tires (ag)	Front: 12.4R34. Rear: 16.9R34
4WD Optional tires (ag)	Front: 13.6-24. Rear: 16.9-34
4WD Optional tires (ag)	Front: 14.5-20. Rear: 16.9R30
4WD Optional tires (ag)	Front: 12.4R24. Rear: 13.6R38
4WD Optional tires (ag)	Front: 11.2-24. Rear: 18.4R30
2WD Optional tires (ag)	Front: 10.00-16. Rear: 16.9R34

Dimensions
2WD Wheelbase	91.3 inches 231 cm
4WD Wheelbase	77.6 inches 197 cm
2WD Length	153.7 inches 390 cm
4WD Length	154.3 inches 391 cm
Width	77.6 inches 197 cm
Height (cab)	102 inches 259 cm
2WD Ground clearance	18.6 inches 47 cm
4WD Ground clearance	16.9 inches 42 cm

Fendt Farmer 306LS Weight
2WD Shipping	7793 lbs 3534 kg
4WD Shipping	8168 lbs 3705 kg
Max capacity	11023 lbs 5000 kg

Attachments

Attachment overview
Fendt 3 loader
Fendt 3S loader

Photos

Fendt Farmer 306 LSA, left side.

Fendt Farmer 306 LSA, right side.

Recommended Implements & Sizing Guide

Engineering recommendations for Fendt Farmer 306LS based on its 70 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	3 to 4 Bottom (16")3 - 4 铧 (40 cm)	Heavy Duty	Suitable for medium loam and stubble turnover.
Rotary Cutter / MowerMowing & Clearing	7 to 8 ft (84-96 in)2.1 - 2.4 m	Heavy Duty	Heavy-duty twin spindle cutter for overgrown acreage.
Rotary TillerSeedbed Prep	78 to 84 in200 - 215 cm	Heavy Duty	Heavy commercial tiller with multi-speed gearbox.
Disc HarrowSecondary Tillage	7 to 8 ft Tandem Disc2.1 - 2.4 m 对开双排耙	Medium Duty	Field leveling and clod breaking behind plows.
Hay BalerHay & Forage	4x4 to 4x5 Round Baler1.2x1.5 m 紧凑圆捆机	Heavy Duty	Silage and dry hay; 540 RPM PTO with slip-clutch.

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Fendt Farmer 306LS.

Estimated Continuous Field Runtime: 7.8 hrs

Approximately 7.8 hours of continuous field operation at ~75% rated power on a full tank (28.3 gal / 107.1 L).

Estimated 75% Load Fuel Burn~3.6 gal/hr (13.8 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours
