Ford LT-11H
The Ford LT-11H is a tractor produced by Ford Lawn Tractors. It is equipped with a 399 cc 24.36 ci engine. The rated power output is 11 hp 8.2 kW. Transmission: Eaton 700. Operating weight: 602 lbs*Weight with 38 inch mower deck. 273 kg.
Engine Power
11 hp
8.2 kW
Fuel & Capacities
1.8 gal
6.8 L
Transmission
Eaton 700
Operating Weight
602 lbs*Weight with 38 inch mower deck.
273 kg
Ford Lawn Tractors Ford LT-11H Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1984 - 1986
LT SeriesLawn tractorGilson built |
|---|---|
1984 - 1986 | |
LT Series | |
Lawn tractor | |
Gilson built | |
1984 - 1986 | |
|---|---|
LT Series | |
Lawn tractor | |
Gilson built |
Production | |
|---|---|
Distributor | Ford |
Manufacturer | Gilson |
Lawn tractor | |
Variants | |
|---|---|
LT-11 | gear |
LT-11H | hydrostatic |
Ford LT-11H Engine | |
|---|---|
11HP Briggs & Stratton 399cc 1-cyl gasoline | |
Fuel tank | 1.8 gal
6.8 L |
Engine details ...  | |
Ford LT-11H Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Disc brakes | |
Open operator station. |
Dimensions & Tires | |
|---|---|
Wheelbase | 49 inches
124 cm |
Weight | 602 lbs
273 kg |
Front tire | 15x6.00-6 |
Rear tire | 18x8.50-8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Lawn, Yard and Garden Equipment published in 1986, by Ford |
Engine
| 1984 - 1986
LT SeriesLawn tractorGilson built |
|---|---|
1984 - 1986 | |
LT Series | |
Lawn tractor | |
Gilson built | |
1984 - 1986 | |
|---|---|
LT Series | |
Lawn tractor | |
Gilson built |
Engine Detail — 399 cc / 24.36 ci Gasoline
Manufacturer | Briggs & Stratton 253707 |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled |
Displacement | 399 cc
24.36 ci |
Bore/Stroke | 3.4375x2.625 inches
87 x 67 mm |
Power | 11 hp
8.2 kW |
Starter volts | 12 |
Oil capacity | 2.25 qts
2.1 L |
Transmission
| 1984 - 1986
LT SeriesLawn tractorGilson built |
|---|---|
1984 - 1986 | |
LT Series | |
Lawn tractor | |
Gilson built | |
1984 - 1986 | |
|---|---|
LT Series | |
Lawn tractor | |
Gilson built |
Transmission — Eaton 700
Transmission | Eaton 700 |
Type | belt-driven hydrostatic |
Gears | infinite forward and reverse |
Dimensions
| 1984 - 1986
LT SeriesLawn tractorGilson built |
|---|---|
1984 - 1986 | |
LT Series | |
Lawn tractor | |
Gilson built | |
1984 - 1986 | |
|---|---|
LT Series | |
Lawn tractor | |
Gilson built |
Ford LT-11H Tires | |
|---|---|
Lawn/turf front | 15x6.00-6 |
Lawn/turf rear | 18x8.50-8 |
Dimensions | |
|---|---|
Wheelbase | 49 inches
124 cm |
Length | 68.5 inches
173 cm |
Width | 35 inches
88 cm |
Height (steering wheel) | 36 inches
91 cm |
Weight | 602 lbs*Weight with 38 inch mower deck.
273 kg |
Attachments
| 1984 - 1986
LT SeriesLawn tractorGilson built |
|---|---|
1984 - 1986 | |
LT Series | |
Lawn tractor | |
Gilson built | |
1984 - 1986 | |
|---|---|
LT Series | |
Lawn tractor | |
Gilson built |
Attachment overview | |
|---|---|
38" mid-mount mower deck | |
Snowblower | |
Blade |
