Ford R-11
The Ford R-11 is a tractor produced by Ford Lawn Tractors. It is equipped with a 399 cc 24.4 ci engine. The rated power output is 11 hp 8.2 kW. Transmission: 5 forward and 1 reverse. Operating weight: 341 lbs 154 kg.
Engine Power
11 hp
8.2 kW
Fuel & Capacities
Gasoline
Transmission
5 forward and 1 reverse
Operating Weight
341 lbs
154 kg
Ford Lawn Tractors Ford R-11 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1984 - 1986
Riding lawn mowerGilson built |
|---|---|
1984 - 1986 | |
Riding lawn mower | |
Gilson built | |
1984 - 1986 | |
|---|---|
Riding lawn mower | |
Gilson built |
Production | |
|---|---|
Distributor | Ford |
Manufacturer | Gilson |
Riding lawn mower | |
Ford R-11 Engine | |
|---|---|
11HP Briggs & Stratton 399cc 1-cyl gasoline | |
Engine details ...  |
Ford R-11 Transmission | |
|---|---|
5-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Dimensions & Tires | |
|---|---|
Wheelbase | 44 inches
111 cm |
Weight | 341 lbs
154 kg |
Front tire | 4.10x3.50-4 |
Rear tire | 16x7.50-8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Lawn, Yard and Garden Equipment published in 1986, by Ford |
Engine
| 1984 - 1986
Riding lawn mowerGilson built |
|---|---|
1984 - 1986 | |
Riding lawn mower | |
Gilson built | |
1984 - 1986 | |
|---|---|
Riding lawn mower | |
Gilson built |
Engine Detail — 399 cc / 24.4 ci Gasoline
Manufacturer | Briggs & Stratton 252707 |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Displacement | 399 cc
24.4 ci |
Bore/Stroke | 3.4375x2.625 inches
87 x 67 mm |
Power | 11 hp
8.2 kW |
Starter | electric |
Starter volts | 12 |
Transmission
| 1984 - 1986
Riding lawn mowerGilson built |
|---|---|
1984 - 1986 | |
Riding lawn mower | |
Gilson built | |
1984 - 1986 | |
|---|---|
Riding lawn mower | |
Gilson built |
Transmission — 5 forward and 1 reverse belt-driven gear
Type | belt-driven gear |
Gears | 5 forward and 1 reverse |
Dimensions
| 1984 - 1986
Riding lawn mowerGilson built |
|---|---|
1984 - 1986 | |
Riding lawn mower | |
Gilson built | |
1984 - 1986 | |
|---|---|
Riding lawn mower | |
Gilson built |
Ford R-11 Tires | |
|---|---|
Lawn/turf front | 4.10x3.50-4 |
Lawn/turf rear | 16x7.50-8 |
Dimensions | |
|---|---|
Wheelbase | 44 inches
111 cm |
Length | 62.5 inches
158 cm |
Height (steering wheel) | 37.5 inches
95 cm |
Weight | 341 lbs
154 kg |
Attachments
| 1984 - 1986
Riding lawn mowerGilson built |
|---|---|
1984 - 1986 | |
Riding lawn mower | |
Gilson built | |
1984 - 1986 | |
|---|---|
Riding lawn mower | |
Gilson built |
30" Mower deck | |
|---|---|
Type | mid-mount Ford |
1-blade | |
Cutting width | 30 inches
76 cm |
Overall width | 44 inches
111 cm |
Cut height | 1.5 to 3.5 inch
3 to 8 cm |
Photos
Ford R-11 tractor photo
