Ford RMT 1130
The Ford RMT 1130 is a tractor produced by Ford Lawn Tractors. The listed engine power is Gasoline (gross): 11 hp / 8.2 kW. Transmission: 3 forward and 1 reverse. Operating weight: 418 lbs 189 kg.
Engine Power
Gasoline (gross): 11 hp / 8.2 kW
Fuel & Capacities
0.75 gal
2.8 L
Transmission
3 forward and 1 reverse
Operating Weight
418 lbs
189 kg
Overview
 | 1980 - 1983
Riding lawn mower |
|---|
Production | |
|---|---|
Manufacturer | Ford |
Riding lawn mower | |
Ford RMT 1130 Engine | |
|---|---|
11HP Briggs & Stratton 1-cyl gasoline | |
Fuel tank | 0.75 gal
2.8 L |
Engine details ...  | |
Ford RMT 1130 Transmission | |
|---|---|
3-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Dimensions & Tires | |
|---|---|
Wheelbase | 44 inches
111 cm |
Weight | 418 lbs
189 kg |
Front tire | 4.10x3.50-4 |
Rear tire | 16x6.50-8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Consumer Products Salesman's Reference published in 1980, by Ford |
Engine
Engine Detail — Gasoline
Manufacturer | Briggs & Stratton |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Power (gross) | 11 hp
8.2 kW |
Air cleaner | dry |
Rated RPM | 3200 |
Starter | electric |
Starter volts | 12 |
Oil capacity | 1.4 qts
1.3 L |
Transmission
Transmission — 3 forward and 1 reverse belt-driven gear
Type | belt-driven gear |
Gears | 3 forward and 1 reverse |
 | |
Dimensions
Ford RMT 1130 Tires | |
|---|---|
Lawn/turf front | 4.10x3.50-4 |
Lawn/turf rear | 16x6.50-8 |
Dimensions | |
|---|---|
Wheelbase | 44 inches
111 cm |
Length | 61.25 inches
155 cm |
Weight | 418 lbs
189 kg |
Attachments
Attachment overview | |
|---|---|
30" mid-mount mower deck | |
Blade |
30" Mower deck | |
|---|---|
Type | mid-mount Ford |
1-blade with manual lift | |
Cutting width | 30 inches
76 cm |
Overall width | 43.375 inches
110 cm |
Cut height | 1.5 to 3.5 inch
3 to 8 cm |
Photos
Ford RMT 1130 tractor photo
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Ford Lawn Tractors Ford RMT 1130.
Estimated Continuous Field Runtime: 1.4 hrs
Approximately 1.4 hours of continuous field operation at ~75% rated power on a full tank (0.8 gal / 2.8 L).
Estimated 75% Load Fuel Burn~0.6 gal/hr (2.2 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Ford Lawn Tractors Ford RMT 1130 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Ford Lawn Tractors Ford RMT 1130.
Converted Equivalents:
Horsepower (HP)11 hp
Kilowatts (kW)8.2 kW
Metric Horsepower (PS / CV)11.2 PS
