Iseki TA550
The Iseki TA550 is a tractor produced by Iseki. It is equipped with a 169.1 ci 2.8 L engine. The listed engine power is Diesel (listed): 52.3 hp / 39.0 kW. Transmission: 16 forward and reverse. Operating weight: 3902 to 4696 pounds.
Engine Power
Diesel (listed): 52.3 hp / 39.0 kW
Fuel & Capacities
13.5 gal
51.1 L
Transmission
16 forward and reverse
Operating Weight
3902 to 4696 pounds
Overview
![]() | 1993 - 1999
Compact Utility tractor |
|---|
Production | |
|---|---|
Manufacturer | Iseki |
Compact Utility tractor | |
Built in Japan | |
Iseki TA550 Engine | |
|---|---|
Isuzu 2.8L 4-cyl diesel | |
Fuel tank | 13.5 gal
51.1 L |
Engine details ... | |
Iseki TA550 Transmission | |
|---|---|
16-speed shuttle | |
Transmission details ... |
Iseki TA550 Power | |
|---|---|
Engine | 52.3 hp
39.0 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Power steering | |
Wet disc brakes | |
Two-post folding ROPS. Cab available with air-conditioning. |
Tractor hitch | |
|---|---|
Rear Type | II/I |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | electro-hydraulic |
Rear PTO Type | 540/1000 (1.375) |
Dimensions & Tires | |
|---|---|
Wheelbase | 79.9 inches
202 cm |
Weight | 3902 to 4696 pounds |
Front tire | 7.5x16 |
2WD Rear tire | 14.9x28 |
Full dimensions and tires ... | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Battery volts | 12 |
References | |
|---|---|
![]() | |
TA Series published in 1993, by Iseki |
Engine
Engine Detail — 169.1 ci / 2.8 L Diesel
Manufacturer | Isuzu 4JB1 |
Fuel Type | Diesel |
Configuration | 4-cylinder, liquid-cooled inline |
Displacement | 169.1 ci
2.8 L |
Bore/Stroke | 3.66x4.02 inches
93 x 102 mm |
Power | 52.3 hp
39.0 kW |
Rated RPM | 2500 |
Torque | 122.9 lb-ft
166.7 Nm |
Torque RPM | 1600 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — 16 forward and reverse shuttle
Type | shuttle |
Gears | 16 forward and reverse |
Four gears in four ranges with synchronized shuttle. | |
Dimensions
Iseki TA550 Tires | |
|---|---|
2WD Standard tires (ag) | Front: 7.5x16. Rear: 14.9x28 |
4WD Standard tires (ag) | Front: 8.3x20. Rear: 14.9x28 |
Dimensions | |
|---|---|
Wheelbase | 79.9 inches
202 cm |
Length | 136.6 inches
346 cm |
Width | 60.8 inches
154 cm |
Height | 63.6 inches
161 cm |
Height (cab) | 93.9 inches
238 cm |
ROPS Weight | 3902 lbs
1769 kg |
Cab Weight | 4696 lbs
2130 kg |
Ground clearance | 14.2 inches
36 cm |
Front tread | 48 to 61.4 inches
121 to 155 cm |
Rear tread | 48 to 63.8 inches
121 to 162 cm |
Photos
Recommended Implements & Sizing Guide
Engineering recommendations for Iseki TA550 based on its 52.3 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 2 to 3 Bottom (14-16")2 - 3 铧 (35-40 cm) | Medium Duty | Standard utility farm tillage. |
Rotary Cutter / MowerMowing & Clearing | 6 ft (72 in)1.8 m | Medium Duty | Medium pasture clearing; rear slip-clutch recommended. |
Rotary TillerSeedbed Prep | 66 to 72 in165 - 180 cm | Medium Duty | Standard utility tiller; slip clutch protection required. |
Disc HarrowSecondary Tillage | 7 to 8 ft Tandem Disc2.1 - 2.4 m 对开双排耙 | Medium Duty | Field leveling and clod breaking behind plows. |
Hay BalerHay & Forage | Small Square Baler (14x18")小方捆打捆机 (36x46 cm) | Medium Duty | Classic 2-string baler for horse and small livestock hay. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Iseki TA550.
Estimated Continuous Field Runtime: 5 hrs
Approximately 5 hours of continuous field operation at ~75% rated power on a full tank (13.5 gal / 51.1 L).
Estimated 75% Load Fuel Burn~2.7 gal/hr (10.3 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Iseki TA550 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Iseki TA550.
Converted Equivalents:
Horsepower (HP)52.3 hp
Kilowatts (kW)39 kW
Metric Horsepower (PS / CV)53 PS
