Iseki TU175

The Iseki TU175 is a tractor produced by Iseki. It is equipped with a 59.7 ci 1.0 L engine. The rated power output is 17.3 hp 12.9 kW. Transmission: 6 forward and 2 reverse. Operating weight: 1466 to 1554 pounds.

Engine Power
17.3 hp 12.9 kW
Fuel & Capacities
4 gal 15.1 L
Transmission
6 forward and 2 reverse
Operating Weight
1466 to 1554 pounds

Iseki TU175 Serial Number & Year Decoder

Find the exact manufacture year of your tractor by checking your chassis serial number below.

Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.

Overview

Iseki TU175 tractor photo
1986 - 1990 Landhope TU5 SeriesCompact Utility tractor
1986 - 1990
Landhope TU5 Series
Compact Utility tractor
Production
Manufacturer
Iseki
Compact Utility tractor
Variants
TU175F
4WD
Iseki TU175 Engine
Mitsubishi 1.0L 3-cyl diesel
Fuel tank
4 gal 15.1 L
Engine details ...
Iseki TU175 Transmission
6-speed gear
Transmission details ...
Iseki TU175 Power
Engine
17.3 hp 12.9 kW
Mechanical
Two- or four-wheel drive
Open operator station.
Power Take-off (PTO)
Rear PTO Type
540 (1.375)
Engine RPM
514@2500
698@2500
1128@2500
Dimensions & Tires
Wheelbase
53.2 inches 135 cm
Weight
1466 to 1554 pounds
Front tire
4.00-12
2WD Rear tire
8.3-22
Full dimensions and tires ...
References
TU175 references literature
Landhope 145 155 165 175 published by Iseki
Landhope 145 155 165 175 (1575-913-001-3D)

Engine

Engine Detail — 59.7 ci / 1.0 L Diesel

Manufacturer
Mitsubishi K3D
Fuel Type
Diesel
Configuration
3-cylinder, liquid-cooled
Displacement
59.7 ci 1.0 L
Bore/Stroke
2.875x3.071 inches 73 x 78 mm
Power
17.3 hp 12.9 kW
Rated RPM
2500
Starter
electric
Starter volts
12

Transmission

Transmission — 6 forward and 2 reverse gear

Type
gear
Gears
6 forward and 2 reverse
TU175 gear speeds

Dimensions

Iseki TU175 Tires
2WD Standard tires (ag)
Front: 4.00-12. Rear: 8.3-22
4WD Standard tires (ag)
Front: 6-12. Rear: 8.3-22
Dimensions
Wheelbase
53.2 inches 135 cm
Length
90.9 inches 230 cm
Width
42.9 inches 108 cm
Height
53.5 inches 135 cm
2WD Weight
1466 lbs 664 kg
4WD Weight
1554 lbs 704 kg
2WD Ground clearance
11 inches 27 cm
4WD Ground clearance
10.2 inches 25 cm
2WD Front tread
29.9 to 31.9 inches 75 to 81 cm
4WD Front tread
33.1 inches 84 cm
Rear tread
33.5 to 39.8 inches 85 to 101 cm

Photos

Iseki TU175 tractor photo

Iseki TU175 tractor photo

Iseki TU175 Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Iseki TU175.

Converted Equivalents:

Horsepower (HP)17.3 hp
Kilowatts (kW)12.9 kW
Metric Horsepower (PS / CV)17.5 PS
