John Deere L108

The John Deere L108 is a tractor produced by John Deere Lawn Tractors. It is equipped with a 501 cc 30.6 ci engine. The listed engine power is Gasoline (gross): 18.5 hp / 13.8 kW. Transmission: Tuff Torq T40. Operating weight: 462 lbs 209 kg.

Overview

	2005 L100 SeriesLawn tractor L100 Series Lawn tractor

Production
Manufacturer	John Deere
Lawn tractor
Built in Greeneville, Tennessee, USA

John Deere L108 Engine
18.5HP Briggs & Stratton 501cc 1-cyl gasoline
Fuel tank	2.1 gal 7.9 L
Engine details ...

John Deere L108 Transmission
hydrostatic
Transmission details ...

Mechanical
Two-wheel drive
Manual steering
Disc brakes
Open operator station.

Power Take-off (PTO)
Mid PTO	independent
Clutch	mechanical

Dimensions & Tires
Wheelbase	48.9 inches 124 cm
Weight	462 lbs 209 kg
Front tire	15x6-6
Rear tire	20x8-8
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	9
Battery volts	12
Battery Group	U1

References
Operator's Manual L100, L108, L111, L118, L120 and L130 (OMGX22058) published in 2005*
*Publication contains known errors.

Engine

Engine Detail — 501 cc / 30.6 ci Gasoline

Manufacturer	Briggs & Stratton 31P677
Fuel Type	Gasoline
Configuration	1-cylinder, air-cooled vertical shaft
Displacement	501 cc 30.6 ci
Bore/Stroke	3.56x3.06 inches 90 x 78 mm
Power (gross)	18.5 hp 13.8 kW
Air cleaner	paper with foam
Starter	electric
Starter volts	12
Sparkplug gap	0.030 inches 0.762 mm
Point gap	0.012 inches 0.305 mm
Intake valve clearance	0.004 inches 0.102 mm
Exhaust valve clearance	0.006 inches 0.152 mm
Oil capacity	2 qts 1.9 L

Transmission

Transmission — Tuff Torq T40

Transmission	Tuff Torq T40
Type	belt-driven hydrostatic
Gears	infinite forward and reverse
Oil change	sealed unit, owner service is not recommended
The K46 was originally advertised for the L108.

Dimensions

John Deere L108 Tires
Lawn/turf front	15x6-6
Lawn/turf rear	20x8-8

Dimensions
Wheelbase	48.9 inches 124 cm
Length	69 inches 175 cm
Width	36 inches 91 cm
Height	38.6 inches 98 cm
Weight	462 lbs 209 kg

Attachments

Attachment overview
42" mid-mount mower deck
Snowblower
Blade

42" Mower deck
Type	mid-mount John Deere
	2-blade with manual lift
Cutting width	42 inches 106 cm
Overall width	44 inches 111 cm
Cut height	1 to 4 inch 2 to 10 cm
Cut positions	7
