John Deere LA100

The John Deere LA100 is a tractor produced by John Deere Lawn Tractors. It is equipped with a 501 cc 30.6 ci engine. The rated power output is 18.5 hp 13.8 kW. Transmission: Dana 4360. Operating weight: 442 lbs 200 kg.

Overview

	2007 LA100 SeriesLawn tractor
2007
LA100 Series
Lawn tractor

Production
Manufacturer	John Deere
Lawn tractor
Built in Greeneville, Tennessee, USA
Original price was $1,499 in 2007

John Deere LA100 Engine
18.5HP Briggs & Stratton 501cc 1-cyl gasoline
Engine details ...

John Deere LA100 Transmission
5-speed gear
Transmission details ...

Mechanical
Two-wheel drive
Manual steering
Open operator station.

Power Take-off (PTO)
Mid PTO	manual

Dimensions & Tires
Wheelbase	48.9 inches 124 cm
Weight	442 lbs 200 kg
Front tire	15x6.00-6
Rear tire	20x8.0-8
Full dimensions and tires ...

Electrical
Ground	negative
Charging amps	9
Battery volts	12

Engine

Engine Detail — 501 cc / 30.6 ci Gasoline

Manufacturer	Briggs & Stratton
Fuel Type	Gasoline
Configuration	1-cylinder, air-cooled
Displacement	501 cc 30.6 ci
Bore/Stroke	3.57x3.06 inches 91 x 78 mm
Power	18.5 hp 13.8 kW
Air cleaner	paper and foam elements
Starter volts	12
Oil capacity	1.5 qts 1.4 L
Sparkplug gap	0.030 inches 0.762 mm

John Deere LA100 Engine
Image courtesy of David Hames

Transmission

Transmission — Dana 4360

Transmission	Dana 4360
Type	belt-driven gear
Gears	5 forward and 1 reverse
Oil change	sealed unit, owner service is not recommended

Dimensions

John Deere LA100 Tires
Lawn/turf front	15x6.00-6
Lawn/turf rear	20x8.0-8

Dimensions
Wheelbase	48.9 inches 124 cm
Length	68.75 inches 174 cm
Width	51.75 inches 131 cm
Height	42.5 inches 107 cm
Weight	442 lbs 200 kg

Attachments

42" Mower deck
Type	mid-mount John Deere
	manual lift
Cutting width	42 inches 106 cm
