John Deere X354

The John Deere X354 is a tractor produced by John Deere Lawn Tractors. It is equipped with a 603 cc 36.8 ci engine. The listed engine power is Gasoline (gross): 18.5 hp / 13.8 kW. Transmission: Tuff Torq K46. Operating weight: 92 lbs 41 kg.

Overview

	2016 - 2025 Model year 2016-20202021-2025 Select X300 SeriesLawn tractor Select X300 Series Lawn tractor

Production
Manufacturer	John Deere
Lawn tractor
Original price was $3,799 in 2016

Variants
X350	2-wheel steering
X354	4-wheel steering
X350R	rear-discharge

John Deere X354 Engine
18.5HP Kawasaki 603cc 2-cyl gasoline
Fuel tank	3.3 gal 12.5 L
Engine details ...

John Deere X354 Transmission
hydrostatic
Transmission details ...

Mechanical
Two-wheel drive
Manual four-wheel steering
Wet disc brakes
Open operator station with 15-inch seat.

Power Take-off (PTO)
Mid PTO	independent
Clutch	electric

Dimensions & Tires
Wheelbase	49.4 inches 125 cm
Weight	544 lbs 246 kg
Front tire	15x6.00-6
Rear tire	20x10-10
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	flywheel alternator
Charging amps	15
Battery CCA	340
Battery volts	12

References
The Complete Range of Lawn Care Solutions published in 2016, by John Deere
Riding Lawn Tractors published in 2017, by John Deere
Riding Lawn Tractors published in 2019, by John Deere
Riding Lawn Tractors published in 2016, by John Deere
Lawn Care Solutions published in 2020, by John Deere
Operator's Manual X300 Tractors (OMM174375) published in 2016
Operator's Manual X300 Tractors (OMUC22094) published in 2019

Engine

Engine Detail — 603 cc / 36.8 ci Gasoline

Manufacturer	Kawasaki FS600V
Fuel Type	Gasoline
Configuration	2-cylinder, air-cooled vertical-shaft V-Twin
Displacement	603 cc 36.8 ci
Bore/Stroke	2.87x2.84 inches 73 x 72 mm
Power (gross)	18.5 hp 13.8 kW
Fuel system	carburetor
Air cleaner	dry with foam precleaner
Rated RPM	3600
Starter	electric
Starter volts	12
Sparkplug gap	0.030 inches 0.762 mm
Oil capacity	1.8 qts 1.7 L
Oil change	100 h

Transmission

Transmission — Tuff Torq K46

Transmission	Tuff Torq K46
Type	belt-driven hydrostatic
Gears	infinite forward and reverse
Oil change	sealed unit, owner service is not recommended

Dimensions

John Deere X354 Tires
Lawn/turf front	15x6.00-6
Lawn/turf rear	20x10-10

Dimensions
Wheelbase	49.4 inches 125 cm
Length	72 inches 182 cm
Width	41 inches 104 cm
Height	47 inches 119 cm
Weight	544 lbs 246 kg
Front axle	Cast-iron

Attachments

Attachment overview
42" mid-mount mower deck
Snowblower
Blade

42" Mower deck
Type	mid-mount John Deere
	2-blade with manual lift*Foot pedal with available assist spring.
Cutting width	42 inches 106 cm
Weight	92 lbs 41 kg
Overall width	50.5 inches 128 cm
Cut height	1 to 4 inch 2 to 10 cm
Cut positions	13
