John Deere Z710A

The John Deere Z710A is a tractor produced by John Deere Lawn Tractors. It is equipped with a 673 cc 41.1 ci engine. The listed engine power is Gasoline (listed): 23 hp / 17.2 kW. Transmission: Tuff Torq. Operating weight: 1092 lbs (48 deck) 495 kg.

Engine Power
Gasoline (listed): 23 hp / 17.2 kW
Fuel & Capacities
7 gal 26.5 L
Transmission
Tuff Torq
Operating Weight
1092 lbs (48 deck) 495 kg

Overview

John Deere Z710A tractor photo
2010 - 2012 Z700 SeriesZero-turn mower Z700 Series Zero-turn mower
Production
Manufacturer
John Deere
Zero-turn mower
Built in Fuquay-Varina, North Carolina, USA
John Deere Z710A Engine
23HP Kohler 673cc 2-cyl gasoline
Fuel tank
7 gal 26.5 L
Engine details ...
John Deere Z710A Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Power steering
Two-post folding ROPS.
Power Take-off (PTO)
Mid PTO
independent
Clutch
electro-magnetic
Dimensions & Tires
Weight
1092 to 1107 pounds
Front tire
13x5-6
Rear tire
22x9.5-12
Full dimensions and tires ...
Electrical
Ground
negative
Battery volts
12
References
Z710A references literature
ZTrak Mowers Z700 Series published in 2010, by John Deere
Operator's Manual Mini-Frame Z-Trak 717 and 727 (OMTCU15693) published in 2002
Operator's Manual ZTrak Z710A and Z720A (OMTCU27952) published in 2010
ZTrak Mowers published in 2011, by John Deere

Engine

Engine Detail — 673 cc / 41.1 ci Gasoline

Manufacturer
Kohler CV680
Fuel Type
Gasoline
Configuration
2-cylinder, air-cooled vertical-shaft V-Twin
Displacement
673 cc 41.1 ci
Bore/Stroke
3.15x2.64 inches 80 x 67 mm
Power
23 hp 17.2 kW
Starter
electric
Starter volts
12
Oil capacity
2 qts 1.9 L

Transmission

Transmission — Tuff Torq

Transmission
Tuff Torq
Type
hydrostatic
Gears
infinite forward and reverse
Oil capacity
2.95 qts*Capacity of each motor. 2.8 L
Z710A  hydrostatic speeds

Dimensions

John Deere Z710A Tires
Lawn/turf front
13x5-6
Lawn/turf rear
22x9.5-12
22x11-10
Dimensions
Length
84 inches 213 cm
Height (ROPS)
73 inches 185 cm
Height (Folded ROPS)
47 inches 119 cm
Weight
1092 lbs (48 deck) 495 kg
1107 lbs (54 deck) 502 kg
Ground clearance
5 inches 12 cm

Attachments

Attachment overview
48" mid-mount mower deck
54" mid-mount mower deck

Photos

John Deere Z710A tractor photo

John Deere Z710A tractor photo

Recommended Implements & Sizing Guide

Engineering recommendations for John Deere Lawn Tractors John Deere Z710A based on its 23 HP power envelope and ASAE agricultural standards.

Implement & OperationRecommended SizeWorkload RatingEngineering Notes
Moldboard PlowPrimary Tillage
1 to 2 Bottom (12")1 - 2 铧 (30 cm)Light DutyIdeal for garden plots and light sandy soil.
Rotary Cutter / MowerMowing & Clearing
4 ft (48 in)1.2 mLight DutyPasture clipping and light brush under 1" diameter.
Rotary TillerSeedbed Prep
42 to 48 in105 - 120 cmLight DutyCovers compact tractor tire width.
Disc HarrowSecondary Tillage
5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片)Light DutySmall acreage soil break-up and secondary aeration.
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for John Deere Lawn Tractors John Deere Z710A.

Estimated Continuous Field Runtime: 5.9 hrs

Approximately 5.9 hours of continuous field operation at ~75% rated power on a full tank (7 gal / 26.5 L).

Estimated 75% Load Fuel Burn~1.2 gal/hr (4.5 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours

John Deere Lawn Tractors John Deere Z710A Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for John Deere Lawn Tractors John Deere Z710A.

Converted Equivalents:

Horsepower (HP)23 hp
Kilowatts (kW)17.2 kW
Metric Horsepower (PS / CV)23.3 PS
