Massey Ferguson 1035

The Massey Ferguson 1035 is a tractor produced by Massey Ferguson. It is equipped with a 91.8 ci 1.5 L engine. The listed engine power is Diesel (listed): 31 hp / 23.1 kW. Transmission: 12 forward and 4 reverse. Operating weight: 2711 to 2935 pounds.

Engine Power

Diesel (listed): 31 hp / 23.1 kW

Fuel & Capacities

7.1 gal 26.9 L

Transmission

12 forward and 4 reverse

Operating Weight

2711 to 2935 pounds

Overview

	1986 - 1991 1000 Compact SeriesCompact Utility tractorToyosha built 1000 Compact Series Compact Utility tractor Toyosha built

Production
Distributor	Massey Ferguson
Manufacturer	Toyosha
Compact Utility tractor
Original price was $12,400 in 1991

Massey Ferguson 1035 Engine
Toyosha 1.5L 3-cyl diesel
Fuel tank	7.1 gal 26.9 L
Engine details ...

Massey Ferguson 1035 Transmission
12-speed gear
Transmission details ...

Massey Ferguson 1035 Power
Engine	31 hp 23.1 kW
PTO (claimed)	26 hp 19.4 kW

Mechanical
Two- or four-wheel drive
Steering	power
Two-post ROPS.

Hydraulics
Type	open center
Pump flow	6 gpm 22.7 lpm

Tractor hitch
Rear Type	I
Rear lift (at ends)	2227 lbs 1010 kg

Power Take-off (PTO)
Rear PTO	live
Rear PTO Type	540 (1.375)

Dimensions & Tires
Wheelbase	67.3 inches 170 cm
Weight	2711 to 2935 pounds
Front tire	5.00-15
Rear tire	13.6-24 (2WD)
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References

Loaders - Compact and Agricultural published in 1989, by Massey Ferguson
Compact Tractors and Implements published in 1987, by Massey Ferguson

Engine

Engine Detail — 91.8 ci / 1.5 L Diesel

Manufacturer	Toyosha MS150
Fuel Type	Diesel
Configuration	3-cylinder, liquid-cooled
Displacement	91.8 ci 1.5 L
Bore/Stroke	3.228x3.740 inches 82 x 95 mm
Power	31 hp 23.1 kW
Fuel system	indirect injection
Air cleaner	dry
Compression	23:1
Rated RPM	2600
Firing order	1-3-2
Starter volts	12
Oil capacity	3.7 qts 3.5 L
Coolant capacity	4.2 qts 4.0 L

Transmission

Transmission — 12 forward and 4 reverse gear

Type	gear
Gears	12 forward and 4 reverse
Clutch	215mm dry disc
Oil capacity	29.6 qts 28.0 L

Dimensions

Massey Ferguson 1035 Tires
Standard tires (ag)	Front: 5.00-15. Rear: 13.6-24 (2WD)
	Front: 7.00-16. Rear: 13.6-24 (4WD)
Lawn/turf front	27x8.50-15
Lawn/turf rear	43x13.5-22

Dimensions
Wheelbase	67.3 inches 170 cm
Length	116.9 inches 296 cm
Width	59.3 inches 150 cm
Height (steering wheel)	60.8 inches 154 cm
Shipping weight	2711 lbs (2WD) 1229 kg
	2935 lbs (4WD) 1331 kg

Attachments

Attachment overview
72" mid-mount mower deck
Blade
Front-end loader
Backhoe

72" Mower deck
Type	mid-mount Massey Ferguson 1019
Cutting width	72 inches 182 cm

Massey Ferguson 1017 Backhoe
Backhoe type	Massey Ferguson 1017 Backhoe

Photos

Massey Ferguson 1035 tractor photo

Recommended Implements & Sizing Guide

Engineering recommendations for Massey Ferguson 1035 based on its 31 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	2 to 3 Bottom (14-16")2 - 3 铧 (35-40 cm)	Medium Duty	Standard utility farm tillage.
Rotary Cutter / MowerMowing & Clearing	5 ft (60 in)1.5 m	Medium Duty	Pasture maintenance and weeds up to 1.5" diameter.
Rotary TillerSeedbed Prep	54 to 60 in135 - 150 cm	Medium Duty	Thorough seedbed preparation in orchards and vegetable plots.
Disc HarrowSecondary Tillage	5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片)	Light Duty	Small acreage soil break-up and secondary aeration.

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Massey Ferguson 1035.

Estimated Continuous Field Runtime: 4.4 hrs

Approximately 4.4 hours of continuous field operation at ~75% rated power on a full tank (7.1 gal / 26.9 L).

Estimated 75% Load Fuel Burn~1.6 gal/hr (6.1 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours
