Murray 4166
The Murray 4166 is a tractor produced by Murray Lawn Tractors. It is equipped with a 655 cc 40 ci engine. The listed engine power is Gasoline (gross): 16 hp / 11.9 kW. Transmission: 4 forward and 1 reverse. Operating weight: 568 lbs 257 kg.
Engine Power
Gasoline (gross): 16 hp / 11.9 kW
Fuel & Capacities
Gasoline
Transmission
4 forward and 1 reverse
Operating Weight
568 lbs
257 kg
Overview
![]() | 1979 - 1981
Garden tractor |
|---|
Production | |
|---|---|
Manufacturer | Murray |
Garden tractor | |
Built in Lawrenceburg, Tennessee, USA | |
Variants | |
|---|---|
82-5211 | Agway model |
GT-16 Twin | similar Sears model |
Murray 4166 Engine | |
|---|---|
16HP Briggs & Stratton 655cc 2-cyl gasoline | |
Engine details ... |
Murray 4166 Transmission | |
|---|---|
4-speed gear | |
Transmission details ... |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Disc brakes | |
Open operator station. |
Tractor hitch | |
|---|---|
Type | sleeve hitch OptOptional |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | manual |
Dimensions & Tires | |
|---|---|
Weight | 568 lbs
257 kg |
Front tire | 16x6.50 |
Rear tire | 23x8.50 |
Full dimensions and tires ... | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
![]() | |
Outdoor Power Equipment published in 1980, by Agway | |
The 1979 Murray Mowers | |
The 1980 Murray Mowers | |
1981 Murray Mowers | |
![]() | |
Murray Parts Microfiche published in 1979 | |
Murray Parts Microfiche published in 1980 | |
Murray Parts Microfiche published in 1981 |
Engine
Engine Detail — 655 cc / 40 ci Gasoline
Manufacturer | Briggs & Stratton |
Fuel Type | Gasoline |
Configuration | 2-cylinder, air-cooled vertical-shaft |
Displacement | 655 cc
40 ci |
Bore/Stroke | 3.44x2.16 inches
87 x 55 mm |
Power (gross) | 16 hp
11.9 kW |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — 4 forward and 1 reverse belt-driven gear
Type | belt-driven gear |
Gears | 4 forward and 1 reverse |
Dimensions
Murray 4166 Tires | |
|---|---|
Lawn/turf front | 16x6.50 |
Lawn/turf rear | 23x8.50 |
Dimensions | |
|---|---|
Weight | 568 lbs
257 kg |
Attachments
Attachment overview | |
|---|---|
42" mid-mount mower deck | |
Snowblower | |
Blade | |
Garden tractors are capable of using tillers, plows, or other ground-engaging attachments. TractorData does not list details of these attachments. |
42" Mower deck | |
|---|---|
Type | mid-mount Murray |
3-blade with manual lift | |
Cutting width | 42 inches
106 cm |
Photos
Recommended Implements & Sizing Guide
Engineering recommendations for Murray Lawn Tractors Murray 4166 based on its 16 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 1 to 2 Bottom (12")1 - 2 铧 (30 cm) | Light Duty | Ideal for garden plots and light sandy soil. |
Rotary Cutter / MowerMowing & Clearing | 4 ft (48 in)1.2 m | Light Duty | Pasture clipping and light brush under 1" diameter. |
Rotary TillerSeedbed Prep | 42 to 48 in105 - 120 cm | Light Duty | Covers compact tractor tire width. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Murray Lawn Tractors Murray 4166.
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Murray Lawn Tractors Murray 4166 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Murray Lawn Tractors Murray 4166.
Converted Equivalents:
Horsepower (HP)16 hp
Kilowatts (kW)11.9 kW
Metric Horsepower (PS / CV)16.2 PS
Direct Competitor Comparison
Compare Murray 4166 against same-era industry alternatives in the same horsepower class.
Current Model
Murray Lawn Tractors
Murray 4166
Engine Power:Gasoline (gross): 16 hp / 11.9 kW
★ Baseline Reference
