County 1254
The County 1254 is a tractor produced by County. It is equipped with a 401 ci 6.6 L engine. The listed engine power is Diesel (gross): 125 hp / 93.2 kW. Transmission: Dual Power. Drive type: 4x4 4WD. Operating weight: 12380 lbs 5615 kg.
Engine Power
Diesel (gross): 125 hp / 93.2 kW
Drive & Traction
4x4 4WD
Fuel & Capacities
43 gal
162.8 L
Transmission
Dual Power
Operating Weight
12380 lbs
5615 kg
Overview
 | 1972 - 1975
Four-wheel Drive (4WD) tractor |
|---|
Production | |
|---|---|
Manufacturer | County |
Four-wheel Drive (4WD) tractor | |
Built in Fleet, England | |
County 1254 Engine | |
|---|---|
Ford 6.6L 6-cyl diesel | |
Fuel tank | 43 gal
162.8 L |
Engine details ...  | |
County 1254 Transmission | |
|---|---|
16-speed two-speed power shift | |
Transmission details ...  |
County 1254 Power | |
|---|---|
Engine (gross) | 125 hp
93.2 kW |
Mechanical | |
|---|---|
Drive | 4x4 4WD |
Power steering | |
Wet disc brakes | |
Cab standard with available air-conditioning. | |
Hydraulics | |
|---|---|
Type | open center |
Pump flow | 12 gpm
45.4 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Control | position and draft control |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 1000 (1.375) |
Engine RPM | 1000@1935 |
Dimensions & Tires | |
|---|---|
Wheelbase | 81 inches
205 cm |
Weight | 12380 lbs
5615 kg |
Front tire | 16.9/14-34 |
Rear tire | 16.9/14-34 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Charging system | alternator |
Battery volts | 12 |
References | |
|---|---|
 | |
1254 - 1454 published in 1972, by County |
Engine
Engine Detail — 401 ci / 6.6 L Diesel
Manufacturer | Ford |
Fuel Type | Diesel |
Configuration | 6-cylinder, liquid-cooled |
Displacement | 401 ci
6.6 L |
Bore/Stroke | 4.40x4.40 inches
112 x 112 mm |
Power (gross) | 125 hp
93.2 kW |
Rated RPM | 2300 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — Dual Power
Transmission | Dual Power |
Type | two-speed power shift |
Gears | 16 forward and 4 reverse |
Dimensions
County 1254 Tires | |
|---|---|
Ag front | 16.9/14-34 |
Ag rear | 16.9/14-34 |
Ag front | 18.4/15-34 |
23.1/18-30 | |
23.1/18-34 | |
Ag rear | 18.4/15-34 |
23.1/18-30 | |
23.1/18-34 | |
Dimensions | |
|---|---|
Wheelbase | 81 inches
205 cm |
Length | 158.7 inches
403 cm |
Width | 90.5 inches
229 cm |
Height (cab) | 116.5 inches
295 cm |
Weight | 12380 lbs
5615 kg |
Ground clearance | 13 inches
33 cm |
Front tread | 68 to 88 inches
172 to 223 cm |
Rear tread | 68 to 88 inches
172 to 223 cm |
Recommended Implements & Sizing Guide
Engineering recommendations for County 1254 based on its 125 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 4 to 5 Bottom (16-18")4 - 5 铧 (40-45 cm) | Heavy Duty | Heavy primary tillage; semi-mounted hitch recommended. |
Rotary Cutter / MowerMowing & Clearing | 10 to 12 ft Flex-Wing3.0 - 3.6 m 折叠双翼 | Heavy Duty | Wide swath pasture and crop residue shredding. |
Rotary TillerSeedbed Prep | 90 to 120 in Heavy Duty230 - 300 cm 重型旋耕机 | Commercial / Field Scale | Deep intensive seedbed preparation for commercial row crops. |
Disc HarrowSecondary Tillage | 15 to 22 ft Folding Disc4.5 - 6.7 m 折叠式圆盘耙 | Commercial / Field Scale | Wide commercial field leveling; requires hydraulic remotes. |
Hay BalerHay & Forage | 5x6 Round Baler or 3x3 Mid Square1.5x1.8 m 大圆捆或中型方捆机 | Heavy Duty | High density baling; requires minimum 85 PTO HP. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for County 1254.
Estimated Continuous Field Runtime: 6.6 hrs
Approximately 6.6 hours of continuous field operation at ~75% rated power on a full tank (43 gal / 162.8 L).
Estimated 75% Load Fuel Burn~6.5 gal/hr (24.6 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
County 1254 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for County 1254.
Converted Equivalents:
Horsepower (HP)125 hp
Kilowatts (kW)93.2 kW
Metric Horsepower (PS / CV)126.7 PS
Direct Competitor Comparison
Compare County 1254 against same-era industry alternatives in the same horsepower class.
Current Model
County
County 1254
Engine Power:Diesel (gross): 125 hp / 93.2 kW
★ Baseline Reference
