Ford YT-16H
The Ford YT-16H is a tractor produced by Ford Lawn Tractors. It is equipped with a 655 cc 40 ci engine. The listed engine power is Gasoline (listed): 16 hp / 11.9 kW. Transmission: Eaton. Operating weight: 475 to 738 pounds.
Engine Power
Gasoline (listed): 16 hp / 11.9 kW
Fuel & Capacities
2.3 gal (early)
8.7 L
Transmission
Eaton
Operating Weight
475 to 738 pounds
Overview
 | 1984 - 1993
Model year 1984-19891990-1993
YT SeriesGarden tractorGilson built
YT Series
Garden tractor
Gilson built |
|---|
Production | |
|---|---|
Distributor | Ford |
Manufacturer | Gilson |
Garden tractor | |
Variants | |
|---|---|
YT-16 | 5-speed |
YT-16H | hydrostatic |
Ford YT-16H Engine | |
|---|---|
16HP Briggs & Stratton 655cc 2-cyl gasoline | |
Fuel tank | 2.3 gal (early)
8.7 L |
4 gal (late)
15.1 L | |
Engine details ...  | |
Ford YT-16H Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | manual sector-and-pinion |
Mechanical caliper-engaged disc on transaxle brakes | |
Open operator station. Optional vinyl cab. | |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Wheelbase | 49 inches
124 cm |
Weight | 475 to 738 pounds |
Front tire | 15x6.00-6 |
Rear tire | 22.5x9.00-12 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging amps | 16 |
Battery CCA | 220 |
Battery volts | 12 |
References | |
|---|---|
 | |
Lawn, Yard and Garden Equipment published in 1986, by Ford | |
Lawn, Yard and Garden Equipment published in 1987, by Ford | |
Lawn, Yard and Garden Tractors - Riding Mowers published in 1988, by Ford |
Engine
Engine Detail — 655 cc / 40 ci Gasoline
Manufacturer | Briggs & Stratton 402707 |
Fuel Type | Gasoline |
Configuration | 2-cylinder, air-cooled |
Displacement | 655 cc
40 ci |
Bore/Stroke | 3.44x2.16 inches
87 x 55 mm |
Power | 16 hp
11.9 kW |
Air cleaner | dual element with precleaner |
Rated RPM | 3600 |
Starter volts | 12 |
Oil capacity | 1.5 qts
1.4 L |
Transmission
Transmission — Eaton
Transmission | Eaton |
Type | belt-driven hydrostatic |
Gears | infinite forward and reverse |
Oil capacity | 1.15 qts
1.1 L |
Eaton 700 used until 1989. Eaton 850 used from 1989 to 1991. | |
 | |
Dimensions
Ford YT-16H Tires | |
|---|---|
Lawn/turf front | 15x6.00-6 |
Lawn/turf rear | 22.5x9.00-12 |
Dimensions | |
|---|---|
Wheelbase | 49 inches
124 cm |
Length | 73 inches
185 cm |
Width | 36 inches
91 cm |
Height (steering wheel) | 39 inches
99 cm |
Shipping weight | 475 lbs
215 kg |
738 lbs (with 42-inch mower)
334 kg | |
Ground clearance | 7 inches (transmission)
17 cm |
Clearance (front axle) | 10 inches
25 cm |
Attachments
Attachment overview | |
|---|---|
42" mid-mount mower deck | |
48" mid-mount mower deck | |
Snowblower | |
Blade | |
Attachments for the YT-16H included a 26-inch rear-mounted tiller with 12-inch time and a 5-inch tilling depth. Two trailer-type lawn sweepers (31 and 38 inch) were available, as were and two dump carts. One was 6-cubic-feet with a 500-pound capacity, the other was 10-cubic-feet with an 800-pound capacity. |
Photos
Ford YT-16H
Recommended Implements & Sizing Guide
Engineering recommendations for Ford Lawn Tractors Ford YT-16H based on its 16 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 1 to 2 Bottom (12")1 - 2 铧 (30 cm) | Light Duty | Ideal for garden plots and light sandy soil. |
Rotary Cutter / MowerMowing & Clearing | 4 ft (48 in)1.2 m | Light Duty | Pasture clipping and light brush under 1" diameter. |
Rotary TillerSeedbed Prep | 42 to 48 in105 - 120 cm | Light Duty | Covers compact tractor tire width. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Ford Lawn Tractors Ford YT-16H.
Estimated Continuous Field Runtime: 2.8 hrs
Approximately 2.8 hours of continuous field operation at ~75% rated power on a full tank (2.3 gal / 8.7 L).
Estimated 75% Load Fuel Burn~0.8 gal/hr (3.1 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Ford Lawn Tractors Ford YT-16H Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Ford Lawn Tractors Ford YT-16H.
Converted Equivalents:
Horsepower (HP)16 hp
Kilowatts (kW)11.9 kW
Metric Horsepower (PS / CV)16.2 PS
