Kubota GR2020

The Kubota GR2020 is a tractor produced by Kubota Lawn Tractors. It is equipped with a 673 cc 41.1 ci engine. The listed engine power is Gasoline (listed): 20.5 hp / 15.3 kW. Transmission: infinite forward and reverse. Operating weight: 882 lbs*Weight with mower deck. 400 kg.

Overview

	2015 - GR SeriesGarden tractor
2015 -
GR Series
Garden tractor

Production
Manufacturer	Kubota
Garden tractor

Kubota GR2020 Engine
20.5HP Kohler 673cc 2-cyl gasoline
Fuel tank	4.2 gal 15.9 L
Engine details ...

Kubota GR2020 Transmission
hydrostatic
Transmission details ...

Mechanical
Four-wheel drive
Power steering
Mechanical drum brakes
Open operator station.

Power Take-off (PTO)
Mid PTO	independent
Clutch	electro-hydraulic wet disc

Dimensions & Tires
Wheelbase	50.4 inches 128 cm
Weight	882 lbs 400 kg
Front tire	16x7.5-8
Rear tire	23x10.50-12
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References
GR Series published in 2019, by Kubota

Engine

Engine Detail — 673 cc / 41.1 ci Gasoline

Manufacturer	Kohler GH631
Fuel Type	Gasoline
Configuration	2-cylinder, air-cooled horizontal-shaft V-Twin
Displacement	673 cc 41.1 ci
Bore/Stroke	3.15x2.64 inches 80 x 67 mm
Power	20.5 hp 15.3 kW
Starter	electric
Starter volts	12

Transmission

Transmission — infinite forward and reverse shaft-driven hydrostatic

Type	shaft-driven hydrostatic
Gears	infinite forward and reverse

Dimensions

Kubota GR2020 Tires
Lawn/turf front	16x7.5-8
Lawn/turf rear	23x10.50-12

Dimensions
Wheelbase	50.4 inches 128 cm
Length	78.3 inches 198 cm
Height (steering wheel)	50.8 inches 129 cm
Weight	882 lbs*Weight with mower deck. 400 kg
Ground clearance	4..7 inches 10 cm
Front tread	32.5 inches 82 cm
Rear tread	32.2 inches 81 cm

Attachments

Attachment overview
48" mower deck
Snowblower
Blade
Garden tractors are capable of using tillers, plows, or other ground-engaging attachments. TractorData does not list details of these attachments.

48" Mower deck
Type	Kubota RCK48GR
	3-blade with hydraulic lift
Cutting width	48 inches 121 cm
Overall width	61 inches 154 cm
Cut height	4 to 4 inch 10 to 10 cm

Photos

Kubota GR2020 tractor photo
