Kubota GR2110
The Kubota GR2110 is a tractor produced by Kubota Lawn Tractors. It is equipped with a 778 cc 47.5 ci engine. The listed engine power is Diesel (gross): 21 hp / 15.7 kW. Transmission: infinite forward and reverse. Operating weight: 948 lbs (with mower) 430 kg.
Overview
![]() | 2008 - 2009
GR SeriesGarden tractor
GR Series
Garden tractor |
|---|
Production | |
|---|---|
Manufacturer | Kubota |
Garden tractor | |
Original price was $8,878 in 2011 | |
Kubota GR2110 Engine | |
|---|---|
21HP Kubota 778cc 3-cyl diesel | |
Fuel tank | 4.8 gal
18.2 L |
Engine details ... | |
Kubota GR2110 Transmission | |
|---|---|
hydrostatic | |
Transmission details ... |
Mechanical | |
|---|---|
Four-wheel drive | |
Steering | Glide Steer, hydrostatic power |
Internal expanding brake brakes | |
Open operator station with adjustable seat and cup holder. | |
Dimensions & Tires | |
|---|---|
Wheelbase | 50.4 inches
128 cm |
Weight | 948 lbs
430 kg |
Front tire | 16x7.5-8 |
Rear tire | 23x10.50-12 |
Full dimensions and tires ... | |
Electrical | |
|---|---|
Ground | negative |
Charging amps | 14.5 |
Battery volts | 12 |
Battery AH | 75 |
Engine
Engine Detail — 778 cc / 47.5 ci Diesel
Manufacturer | Kubota D782 |
Fuel Type | Diesel |
Configuration | 3-cylinder, liquid-cooled |
Displacement | 778 cc
47.5 ci |
Power (gross) | 21 hp
15.7 kW |
Rated RPM | 3200 |
Starter | electric |
Starter volts | 12 |
Oil capacity | 3 qts
2.8 L |
Transmission
Transmission — infinite forward and reverse hydrostatic
Type | hydrostatic |
Gears | infinite forward and reverse |
Oil capacity | 2.6 qts
2.5 L |
Treadle-pedal foot control with cruise control. | |
![]() | |
Dimensions
Kubota GR2110 Tires | |
|---|---|
Ag front | 16x7.50-8 |
Ag rear | 23x10.5-12 |
Lawn/turf front | 16x7.5-8 |
Lawn/turf rear | 23x10.50-12 |
Dimensions | |
|---|---|
Wheelbase | 50.4 inches
128 cm |
Length | 77.1 inches
195 cm |
Width | 66.3 inches
168 cm |
Height | 48.4 inches
122 cm |
Weight | 948 lbs (with mower)
430 kg |
Attachments
Attachment overview | |
|---|---|
48" mid-mount mower deck | |
54" mid-mount mower deck | |
Garden tractors are capable of using tillers, plows, or other ground-engaging attachments. TractorData does not list details of these attachments. |
Photos
Recommended Implements & Sizing Guide
Engineering recommendations for Kubota Lawn Tractors Kubota GR2110 based on its 21 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 1 to 2 Bottom (12")1 - 2 铧 (30 cm) | Light Duty | Ideal for garden plots and light sandy soil. |
Rotary Cutter / MowerMowing & Clearing | 4 ft (48 in)1.2 m | Light Duty | Pasture clipping and light brush under 1" diameter. |
Rotary TillerSeedbed Prep | 42 to 48 in105 - 120 cm | Light Duty | Covers compact tractor tire width. |
Disc HarrowSecondary Tillage | 5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片) | Light Duty | Small acreage soil break-up and secondary aeration. |
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Kubota Lawn Tractors Kubota GR2110.
Estimated Continuous Field Runtime: 4.4 hrs
Approximately 4.4 hours of continuous field operation at ~75% rated power on a full tank (4.8 gal / 18.2 L).
Engine Crankcase Oil
Transmission & Hydraulic System
Engine Cooling System
Kubota Lawn Tractors Kubota GR2110 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Kubota Lawn Tractors Kubota GR2110.
Converted Equivalents:
Direct Competitor Comparison
Compare Kubota GR2110 against same-era industry alternatives in the same horsepower class.
Kubota GR2110
International Harvester D-219
