Kubota ZD326

The Kubota ZD326 is a tractor produced by Kubota Lawn Tractors. It is equipped with a 1001 cc 61.1 ci engine. The listed engine power is Diesel (gross): 26 hp / 19.4 kW. Transmission: infinite forward and reverse. Operating weight: 1700 lbs 771 kg.

Overview

	2007 - 2017 Z300 SeriesZero-turn mower Z300 Series Zero-turn mower

Production
Manufacturer	Kubota
Zero-turn mower
Original price was $14,586 in 2015

Kubota ZD326 Engine
26HP Kubota 1001cc 3-cyl diesel
Fuel tank	12.9 gal 48.8 L
Engine details ...

Kubota ZD326 Transmission
hydrostatic
Transmission details ...

Mechanical
Two-wheel drive
Steering	differential power
Wet discs brakes
Two-post foldable ROPS.

Power Take-off (PTO)
Mid PTO	independent
Clutch	hydraulic wet disc

Dimensions & Tires
Wheelbase	55.5 inches 140 cm
Weight	1700 lbs 771 kg
Front tire	15x6.0-6
Rear tire	26x12.0-12
Full dimensions and tires ...

Electrical
Ground	negative
Charging amps	14
Charging volts	14
Battery CCA	475
Battery volts	12

References
Z200/Z300 Series published in 2016, by Kubota

Engine

Engine Detail — 1001 cc / 61.1 ci Diesel

Manufacturer	Kubota D1005
Fuel Type	Diesel
Configuration	3-cylinder, liquid-cooled
Displacement	1001 cc 61.1 ci
Bore/Stroke	2.992x2.898 inches 76 x 74 mm
Power (gross)	26 hp 19.4 kW
Rated RPM	3200
Starter	electric
Starter volts	12

Transmission

Transmission — infinite forward and reverse hydrostatic

Type	hydrostatic
Gears	infinite forward and reverse

Dimensions

Kubota ZD326 Tires
Lawn/turf front	15x6.0-6
Lawn/turf rear	26x12.0-12

Dimensions
Wheelbase	55.5 inches 140 cm
Length	87.4 inches 221 cm
Width	57.5 inches 146 cm
Height (ROPS)	75.4 inches 191 cm
	61.2 inches (folded) 155 cm
Weight	1700 lbs 771 kg
Front tread	38.4 inches 97 cm
Rear tread	45.3 inches 115 cm

Attachments

60" Mower deck
Type	mid-mount Kubota RCK60P-331Z
	3-blade
Cutting width	60 inches 152 cm
Overall width	75.2 inches 191 cm
Cut height	1 to 5 inch 2 to 12 cm

Photos

Kubota ZD326
