Simplicity Broadmoor 18/44

The Simplicity Broadmoor 18/44 is a tractor produced by Simplicity Lawn Tractors. The listed engine power is Gasoline (gross): 18 hp / 13.4 kW. Transmission: Tuff Torq K57. Operating weight: 580 lbs 263 kg.

Overview

	2005 - 2006 Broadmoor SeriesLawn tractor Broadmoor Series Lawn tractor

Production
Manufacturer	Simplicity (a part of Briggs & Stratton)
Lawn tractor
Original price was $3,850 in 2006

Simplicity Broadmoor 18/44 Engine
18HP Kohler 1-cyl gasoline
Fuel tank	4 gal 15.1 L
Engine details ...

Simplicity Broadmoor 18/44 Transmission
hydrostatic
Transmission details ...

Mechanical
Two-wheel drive
Manual steering
Open operator station.

Power Take-off (PTO)
Front PTO	independent
Front PTO Type	electric

Dimensions & Tires
Weight	580 lbs 263 kg
Front tire	15x6.0-6
Rear tire	22x10.0-10
Full dimensions and tires ...

References
The Way To A Beautiful Lawn published in 2005, by Simplicity

Engine

Engine Detail — Gasoline

Manufacturer	Kohler Command
Fuel Type	Gasoline
Configuration	1-cylinder, air-cooled vertical-shaft
Power (gross)	18 hp 13.4 kW
Starter	electric
Starter volts	12

Transmission

Transmission — Tuff Torq K57

Transmission	Tuff Torq K57
Type	belt-driven hydrostatic
Gears	infinite forward and reverse

Dimensions

Simplicity Broadmoor 18/44 Tires
Lawn/turf front	15x6.0-6
Lawn/turf rear	22x10.0-10

Dimensions
Width	37 inches 93 cm
Weight	580 lbs 263 kg

Attachments

44" Mower deck
Type	mid-mount Simplicity
	3-blade
Cutting width	44 inches 111 cm
